Sony DME-3000 - BKDM-3030 Non-Linear Effects Board; BKDM-3040 Wipe;Graphics Board; BKDM-3050 Combiner;Lighting Board; BKDM-3060 Key Channel;Recursive Effects Board

22(E)
BKDM-3030 Non-Linear Effects
Board
General
Power requirements
5 V ± 0.2 V DC
Power consumption
20 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F)
Dimensions 317 × 20 × 220.8 mm (12
1
/2 ×
13
/16 ×
8
3
/4 inches) (w/h/d, excluding
projections)
Mass 0.5 kg (1 lb 1 oz)
Other
CPU R3081, clock frequency 25 MHz
BKDM-3040 Wipe/Graphics
Board
General
Power requirements
5 V ± 0.2 V DC
Power consumption
25 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95°F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, excluding
projections)
Mass 1.3 kg (2 lb 13 oz)
Other
CPU R3081, clock frequency 25 MHz
Specifications
BKDM-3050 Combiner/Lighting
Board
General
Power requirements
5 V ± 0.2 V DC
–5 V ± 0.1 V DC
Power consumption
50 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, excluding
projections)
Mass 1.3 kg (2 lb 13 oz)
Input/output
Input/output Component/Composite serial
digital signal (VIDEO/Y, EXT/C,
KEY/Z, Z)
BKDM-3060 Key Channel/
Recursive Effects Board
General
Power requirements
5 V +0.2 V DC
Power consumption
20 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95°F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, (excluding
projections)
Mass 1.2 kg (2 lb 10 oz)
