23(E)
Other
Memory capacity Key channel block: 1 frame
Recursive block: 2 frames
BKDM-7020 Digital Input/Output
Board
General
Power requirements
5 V ±0.2 V DC, –5 V ±0.1V DC,
12 V ±1 V DC
Power consumption
40 W
Temperature range
Operation guaranteed: 5°C to 40°C (41°F to 104°F)
Performance guaranteed: 10°C to 35°C (50°F to
95°F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, excluding
projections)
Mass 1.3 kg (2 lb 13 oz)
BKDM-7021 Digital Color Effect
Board
Power requirements
5 V ±0.2 V DC
Power consumption
10 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F )
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F )
Dimensions 205 × 10 × 110 mm (8
1
/8 ×
13
/42 ×
4
3
/8 inches) (w/h/d, excluding
projections)
Mass 0.15kg (5 oz)
BKDM-7031 Digital Sparkle
Effects Board
Power requirements
5 V ±0.2 V DC
Power consumption
5 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F )
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F )
Dimensions 110 × 10 × 162 mm (4
3
/8 ×
13
/32 ×
6
1
/2 inches) (w/h/d, excluding
projections)
Mass 0.1kg (3 oz)
BKDM-7041 Digital Sketch
Effects Board
Power requirements
5 V ±0.2 V DC
Power consumption
15 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F )
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F )
Dimensions 158 × 10 × 220 mm (6
1
/4 ×
13
/32 ×
8
3
/4 inches) (w/h/d, excluding
projections)
Mass 0.15 kg (5 oz)
