Sony DME-3000 - BKDM-3022 Composite Digital;Analog Input;Output Board; BKDM-3023 Component Digital;Analog Input;Output Board

21(E)
Input/output
Input Component serial digital signal
(VIDEO A/B, KEY A/B)
Reference signal
(black burst or composite sync)
Output Component serial digital signal
(VIDEO 1/2, KEY 1/2)
BKDM-3022 Composite Digital/
Analog Input/Output Board
General
Power requirements
5 V ± 0.2 V DC
–5 V ± 0.1 V DC
12 V ± 1 V DC
Power consumption
60 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, excluding
projections)
Mass 1.4 kg (3 lb 1 oz)
Input/output
Input Composite serial digital signal
(VIDEO A/B, KEY A/B)
Analog NTSC signal
(VIDEO A/B, KEY A/B)
Reference signal (black burst )
Output Composite serial digital signal
(VIDEO 1/2, KEY 1/2)
Analog NTSC signal
(VIDEO 1/2, KEY 1/2)
BKDM-3023 Component Digital/
Analog Input/Output Board
General
Power requirements
5 V ± 0.2 V DC
–5 V ± 0.1 V DC
12 V ± 1 V DC
Power consumption
60 W
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F)
Dimensions 317 × 20 × 380 mm (12
1
/2 ×
13
/16 ×
15 inches) (w/h/d, excluding
projections)
Mass 1.4 kg (3 lb 1 oz)
Input/output
Input Component serial digital signal
(VIDEO A/B, KEY A/B)
Analog component signal
(Y/R–Y/B–Y A/B, KEY A/B)
Reference signal (black burst or
composite sync)
Output Component serial digital signal
(VIDEO 1/2, KEY 1/2)
Analog component signal
(Y/R–Y/B–Y 1/2, KEY 1/2),
switchable to R/G/B/SYNC
output
