Sony DME-3000 - DVS-8000;8000 C Digital Video Switcher and DME-5000 Digital Multi Effects Connections

16(E)
DVS-8000/8000C Digital Video Switcher and DME-5000 Digital Multi
Effects Connections
DVS-8000/8000C and DME-5000 connections
System Configuration
K
V
K
K
V
K
K
V
V
V
BKDS-8010 Switcher Control Panel
b)
DME
DME-5000
Digital Multi Effects
CONTROL PANEL
SWITCHER
DIGITAL OUTPUTS
PRIMARY INPUTS
DME
DIGITAL INPUTS
AUX BUS OUTPUTS 1, 2
COMBINER
OUTPUTS
a)
CONTORL
PANEL
AUX BUS
c)
DVS-8000/
8000C Digital
Video Switcher
COMBINER
INPUTS
DIGITAL
INPUTS
DME-3000/7000
AUX
AUX BUS
OUTPUTS 3, 4
PRIMARY
INPUTS
DIGITAL
OUTPUTS
SWITCHER PANEL
: Loop-through connection
: 9-pin remote cable
: 75-ohm coaxial cable
: Video signals
: Key signals
a) Combining images from the DME-5000
and DME-3000/7000 requires the
optional BKDM-5020A or BKDM-
5021A board to be installed in the
DME-5000.
b) Up to four DME units can be controlled
from the BKDS-8010. Of these, up to
two can be DME-3000 units. Up to four
DME-7000 units can be controlled
simultaneously. However, certain
DME-3000/7000 functions are subject
to restrictions when controlled from the
BKDS-8010.
c) Component mode: Connect to VIDEO/
Y, KEY/Z and Z connectors using 3
cables.
Composite mode: Connect to VIDEO/
Y, EXT/C, KEY/Z and Z connectors
using 4 cables.
d) These connectors are provided only on
the DME-7000.
d) d)
