Specifications
Following specifications show the reference
performance for this unit and individual accessories.
Design and specifications are subject to change
without notice.
DME-3000/7000 Digital Multi
Effects
General
Power requirement
90 to 264 V AC, 50/60 Hz
Power consumption
Approx. 400 W (with all optional
boards installed)
Supply power factor
90% or above
Temperature range
Operation guaranteed: 5˚C to 40˚C (41˚F to 104˚F)
Performance guaranteed: 10˚C to 35˚C (50˚F to
95˚F)
Storage: –20˚C to +55˚C (–4˚F to +131˚F)
Relative humidity
Operation guaranteed: 80% or less
Performance guaranteed: 70% or less
Dimensions 424 × 221.2 × 450 mm (16
3
/4 × 8
3
/4
× 17
3
/4 inches) (w/h/d, excluding
projections)
Mass 27 kg (55 lb 1 oz) (with all optional
boards installed)
Input/output connectors
DIGITAL INPUTS
•Component
VIDEO: Serial digital signal input, BNC (×2), 75 Ω
KEY: Serial digital signal input, BNC (×2), 75 Ω
•Composite
VIDEO: Serial digital signal input, BNC (×2), 75 Ω
KEY: Serial digital signal input, BNC (×2), 75 Ω
DIGITAL OUTPUTS
•Component
VIDEO: Serial digital signal output, BNC (×2), 75 Ω
KEY: Serial digital signal output, BNC (×2), 75 Ω
•Composite
VIDEO: Serial digital signal output, BNC (×2), 75 Ω
KEY: Serial digital signal output, BNC (×2), 75 Ω
ANALOG INPUTS
•Component
Y, R–Y, B–Y: Analog component signal input, BNC
(×6)
Y: 1 Vp-p, with sync signal
R–Y, B–Y: 0.7 Vp-p
KEY: VS, 1 Vp-p, BNC (×2)
VIDEO/Y/EXT (A): Serial digital signal input, BNC
(×1), 75 Ω (only when the BKDM-7020 is
installed)
•Composite
VIDEO: Analog composite signal input (SCH ±35°),
BNC (×2)
KEY: VS, 1 Vp-p, BNC (×2)
VIDEO/Y/EXT (A): Serial digital signal input, BNC
(×1), 75 Ω (only when the BKDM-7020 is
installed)
ANALOG OUTPUTS
•Component
Y, R–Y, B–Y (when outputting color difference
signal) : Analog component signal output, BNC
(×6)
Y: 1 Vp-p, with sync signal
R–Y, B–Y: 0.7 Vp-p
R, G, B, SYNC (when outputting RGB signal):
Analog RGB signal output, BNC (×8)
R, G, B: 0.7 Vp-p
SYNC: 2.35 Vp-p
KEY: VS, 1 Vp-p, BNC (×2)
•Composite
VIDEO: Analog composite signal output, BNC (×2)
KEY: VS, 1 Vp-p, BNC (×2)
REF INPUT
•Component
Analog reference signal input, BNC (×2), black burst
or composite sync, 0.3 to 2 Vp-p, loop-through
•Composite
Analog reference signal input, BNC (×2), black burst
(SCH ±35°), loop-through
COMBINER INPUTS
•Component
VIDEO, KEY, Z Serial digital signal input, BNC
(×3)
•Composite
Y, C, KEY, Z Serial digital signal input, BNC (×4)
