COMBINER OUTPUTS
•Component
VIDEO, KEY, Z Serial digital OUTPUTS signal
output, BNC (×3)
•Composite
Y, C, KEY, Z Serial digital signal output, BNC (×4)
EXTERNAL INPUT
•Component
EXT Serial digital signal input, BNC (×1)
Remote control signal
CONTROL PANEL
Complies with RS-422A standard,
D-sub 9-pin (×2) and D-sub 25-
pin (×2)
EDITOR Complies with RS-422A standard,
D-sub 9-pin
SWITCHER PANEL
Complies with RS-422A standard,
D-sub 9-pin (×2)
AUX Complies with RS-422A standard,
D-sub 9-pin (×2)
GPI 4 inputs, 4 outputs, programmable,
D-sub 15-pin
NETWORK (DME-7000 only)
Complies with Ethernet 10 BASE-
5, D-sub 15-pin
TERMINAL (DME-7000 only)
Complies with RS-232C standard,
D-sub 9-pin
Performance (when inputting and
outputting analog signals)
Linearity (composite)
Differential gain: 2% maximum
Differential phase: 2° maximum
(measured with a ramp signal on
which 40 IRE sub-carrier signal
is superimposed)
Frequency response
Component
Y: 500 kHz to 5 MHz, ±0.8 dB
R–Y, B–Y: 500 kHz to 2.5 MHz,
±0.8 dB
Composite: 500 kHz to 4.2 MHz,
±0.5 dB
Pulse characteristics
K: 1% maximum, 2T pulse
S/N ratio Component: 55 dB or above
Composite: 55 dB or above
Y/C delay Component: 20 ns maximum
Composite: 15 ns maximum
Sampling
Clock frequency Component: 13.5 MHz
Composite: 14.3 MHz
Quantization Analog: 10 bits
Digital I/O: 10 bits
Internal processing: 10 to 12 bits
System delay
System delay 1 frame
Input phase adjustment range
–0.3H to +1.8H
Accessories supplied
Rack mounting angles (1 set, fitted to cabinet)
Power cord (1) (DME-3000 only)
Plug adaptor for power cord (1) (DME-3000 only)
Plug holder (2) (DME-3000 only)
D-sub 25-pin cable, 10 m (1)
75 Ω terminator (1)
Operation Manual (1)
Maintenance Manual Part 1 (1)
Accessories not supplied
AC Power cord (for DME-7000 only)
For the USA and Canada : DK-2401 AC Power Cord
For the U.K.: Part No. 1-590-910-11
Plug retainer (for DME-7000 only)
For the USA and Canada :2-990-242-01
For the U.K.: Part No. 3-170-078-01
SWC-2530D D-sub 25-pin cable, 30 m
BZDM-3020/7020 Operation Software with Manual
CPD-15SF8 Data Display Unit
