Adjust the white balance standard data at 3200K.
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Adjustment Page F
Adjustment Address 80 to 83, 86, 87
Note 1: Perform this data input after performing “Auto White
Balance 3200K Standard Data Input 2”.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 3: “Auto White Balance 3200K Standard Data Input 3” is
available only once after the power is turned on. Turn the
power off, then on again if the adjustment is retried.
Adjusting method:
Order Page Address Data Procedure
1
“Auto White Balance 3200K
Standard Data Input 2” is
completed.
2 6 37 06
3 6 01 0B Press PAUSE button. (Note 4)
46 02
Check the data changes to
“01”.
Note 4: The adjustment data will be automatically input to page:
F, address: 80 to 83 and 86 to 87.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 01 00 Press PAUSE button.
2
Perform “Auto White
Balance 5800K Standard
Data Input 1”.
12. Auto White Balance 5800K Standard Data Input 1
RadarW
RadarW
Adjust the white balance standard data at 5800K.
Mode CAMERA
Subject Clear chart
(Standard picture frame with the
zoom lens at WIDE end)
Filter Filter C14 for color temperature
correction
Adjustment Page F
Adjustment Address 88 to 91, A0 to A3, B1, B3
Note 1: Perform this data input after performing “Auto White
Balance 3200K Standard Data Input 3”.
Note 2: Check that the data of page: 6, address: 02 is “00”.
If not, turn the power of unit OFF/ON.
Note 3: “Auto White Balance 5800K Standard Data Input 1” is
available only once after the power is turned on. Turn the
power off, then on again if the adjustment is retried.
Adjusting method:
Order Page Address Data Procedure
1
“Auto White Balance 3200K
Standard Data Input 3” is
completed.
2
Place the C14 filter on the
lens.
3 F A0 2B Press PAUSE button.
4 F A1 10 Press PAUSE button.
5 F A2 5D Press PAUSE button.
6 F A3 E0 Press PAUSE button.
7 6 37 07
86 B603
9 6 01 11 Press PAUSE button.
10 6 38
Check the data changes to
“01”.
11 6 01 C3 Press PAUSE button. (Note 4)
12 6 02
Check the data changes to
“01”.
13 6 01 00 Press PAUSE button.
14 6 B6 00
15 6 37 08
16 6 01 A5 Press PAUSE button. (Note 4)
17 6 02
Check the data changes to
“01”.
Note 4: The adjustment data will be automatically input to page:
F, address: 88 to 91, A0 to A3, B1 and B3.
Processing after Completing Adjustment:
Order Page Address Data Procedure
1 6 01 00 Press PAUSE button.
2
Perform “Auto White
Balance 5800K Standard
Data Input 2”.
