Specifications
15
Specifications
General
Power requirements
When supplied via the CCU connector:
180 V DC
When supplied via the DC IN
connector: 12 V DC (10.5 to 17 V
DC)
Power consumption
When 180 V DC is supplied via the
CCU connector: max. 0.37 A
When 12 V DC is supplied via the DC
IN connector: max. 4.8 A
Operating temperature
–10ºC to +45ºC (14ºF to 113ºF)
Operating humidity
20% to 90%
Storage temperature
–20ºC to +60ºC (–4ºF to 140ºF)
Mass Approx. 2.3 kg (5 lb 1 oz)
External dimensions
206 × 212 × 131 mm
(8 1/8 × 8 3/8 × 5 1/4 inches) (w/h/d)
Input/output connectors
CCU CA-TX50: Kings triaxial connector
(made by Lemo)
CA-TX50P: Fischer triaxial connector
PROMPTER BNC, 1.0 Vp-p, 75 Ω
RETURN BNC, 1.0 Vp-p, 75 Ω
INTERCOM/PROGRAM
XLR 5-pin
Input level: –60 dBs (dynamic)
Output level: –∞ to +12 dBs
AUDIO IN CH1/CH2
XLR 3-pin, female, 600 Ω, balanced
Input level: –60 dB (for microphone
input) or –20 dB (for line input)
DC IN XLR 4-pin, 10.5 to 17 V DC
DC OUT 4-pin, 10.5 to 17 V DC, max. 1.5 A
Camera connector
PRO 76-pin DIGITAL
EARPHONE Mini jack
Accessories supplied
Operating Instructions (1)
CD-ROM (including multi-lingual operating
instructions) (1)
Warranty booklet (1)
Accessories not supplied
Triaxial cable (Belden)
AC-DN10 AC Adaptor
WRR-861*/862 series UHF Portable Tuner
DXF-51 viewfinder
* WRR-861 series UHF Portable tuner is not available in some areas.
For details, contact your Sony dealer.
Design and specifications are subject to change without
notice.
