Specifications
21
PAL: 700 mVp-p, 75 ohms
Encoded output: 1.0 Vp-p, 75 ohms
WF MODE 4-pin (1)
AUDIO OUTPUT
XLR, 3-pin
0 dBu/–20 dBu, balanced, 2 channels
SYNC BNC type
2) R/G/B/and Y/R-Y/B-Y are switchable.
Camera input/output signals
CAMERA Triax (Kings type for the U.S.A.
and Canada, Fischer type for Europe)
COAX BNC type (1), 75 ohms
REMOTE 10-pin, multi connector
INTERCOM/TALLY/PGM
D-sub, 25-pin (1)
4W/RTS
TALLY: 24 V DC, TTL level or
contact selectable
MIC REMOTE D-sub, 15-pin (1)
INCOM (on the front panel)
XLR, 5-pin (1)
Supplied accessories
AC power cord (1)
AC power plug holder (1)
Number plate (1 set)
Operating Instructions (1)
CD-ROM (including multi-lingual operating
instructions) (1)
Warranty booklet (1)
Optional accessories
Remote Control Panel RCP-D50
Rack Mount Bracket RMM-301
Design and specifications are subject to change without
notice.
