Overview
ID: ILL-SONY-17PE-FRONT-OVERVIEW
ID: ILL-SONY-17PE-BACK-OVERVIEW
1. Charging/Notification light
2. Headset jack
3. Front camera lens
4. Second microphone
5. Ear speaker
6. Proximity/Light sensor
7. Volume button
8. Power key
9. Main microphone
10. Charger/USB Type-C™ [USB Type-C-tm]
cable port
11. Speaker
12. Wi-Fi [udoc_no_trans_wifi_wlan_plain] /GPS/
Bluetooth antenna area
13. Main camera lens
14. Flash
15. Nano SIM/Memory card slot cover
16. NFC™ detection area
17. Main antenna area
