Sony HAP-S1 User Manual

You can adjust bass and treble to your desired tone using the Tone Control function. Bass and
treble can each be adjusted between levels –10 and +10.
1. Select [Settings] - [Audio Settings] from the Home screen.
2. Select [Tone Control].
The Tone Control screen appears.
3. Push the jog dial in again.
The Tone Control setup screen appears with the bass gain icon ( ) highlighted.
4. Turn the jog dial to adjust the bass and then push it in.
The screen changes back to the Tone Control screen.
5. Turn the jog dial to select the “Treble” segment and then repeat the operations in steps 3
and 4.
Setting of the bass and treble is complete.
Note
You cannot set bass and treble while [Tone Control Bypass] in the menu is set to [On].
The frequency of Bass or Treble remains fixed even if you change the level of bass or treble.
Hint
You can also set this function using the Playback Options menu during playback.

Sony HAP-S1 Specifications

General

Product color	Silver
Audio formats supported	AAC, AIFF, ALAC, FLAC, LPCM, MP3, WAV, WMA
Impedance	16 Ω
Frequency range	10 - 100000 Hz
Audio output channels	2.0 channels
Signal-to-Noise Ratio (SNR)	100 dB
Channels quantity	2 channels
Wi-Fi	Yes
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Automatic synchronization	You don't have to change personal settings when first connecting your device. Your device is automatically synchronized with the settings of your car, so once you have done it for the car, that's it!
Storage media type	HDD
Total storage capacity	500 GB
HDCP	No
Headphone outputs	1
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	0
AC input voltage	230 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	0.3 W
Display diagonal	4.3 \

Weight and Dimensions

Width	- mm
Weight	- g
