46
DAV-DZ350/DZ650/DZ950
SECTION 7
ELECTRICAL PARTS LIST
9-885-183-81 FUNCTION KEY BOARD, COMPLETE
(Included in complete PANEL, SWITCH board)
****************************
************************************************************
9 9-885-183-50 MAIN BOARD, COMPLETE (DZ350: E12)
9 9-885-183-51 MAIN BOARD, COMPLETE (DZ350: E3) (Former)
(See Note 3)
9 9-885-183-52 MAIN BOARD, COMPLETE (DZ350: E93) (Former)
(See Note 3)
9 9-885-183-53 MAIN BOARD, COMPLETE (DZ350: EA)
9 9-885-183-54 MAIN BOARD, COMPLETE (DZ350: SAF)
9 9-885-183-55 MAIN BOARD, COMPLETE (DZ350: SP1)
9 9-885-183-56 MAIN BOARD, COMPLETE (DZ650: E3) (Former)
(See Note 3)
9 9-885-183-57 MAIN BOARD, COMPLETE (DZ650: E93) (Former)
(See Note 3)
9 9-885-183-58 MAIN BOARD, COMPLETE (DZ650: RU)
9 9-885-183-59 MAIN BOARD, COMPLETE (DZ650: SP1)
9 9-885-183-60 MAIN BOARD, COMPLETE (DZ650: TH)
9 9-885-183-61 MAIN BOARD, COMPLETE (DZ950: E3) (Former)
(See Note 3)
9 9-885-183-62 MAIN BOARD, COMPLETE (DZ950: E93) (Former)
(See Note 3)
9 9-885-183-63 MAIN BOARD, COMPLETE (DZ950: EA)
9 9-885-183-64 MAIN BOARD, COMPLETE (DZ950: SP1)
9 9-885-183-65 MAIN BOARD, COMPLETE (DZ950: TH)
9 9-885-185-01 MAIN BOARD, COMPLETE (DZ650: EA)
9 9-885-185-35 MAIN BOARD, COMPLETE (DZ650: CEL)
9 9-885-185-36 MAIN BOARD, COMPLETE (DZ950: CEL)
9 9-885-186-37 MAIN BOARD, COMPLETE (DZ350: TH)
9 9-885-194-88 MAIN BOARD, COMPLETE (DZ350: E3) (New)
(See Note 3)
9 9-885-194-89 MAIN BOARD, COMPLETE (DZ350: E93) (New)
(See Note 3)
9 9-885-194-90 MAIN BOARD, COMPLETE (DZ650: E3) (New)
(See Note 3)
9 9-885-194-91 MAIN BOARD, COMPLETE (DZ650: E93) (New)
(See Note 3)
9 9-885-194-92 MAIN BOARD, COMPLETE (DZ950: E3) (New)
(See Note 3)
9 9-885-194-93 MAIN BOARD, COMPLETE (DZ950: E93) (New)
(See Note 3)
********************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
CEL : Turkish model
E3 : Middle East & African (Except
country of E93 area and South
African) models
E12 : Indian model
E93 : Iraqi, Kuwait, UAE, Kenyan,
Nigerian and Tanzanian models
EA : Saudi Arabia model
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
< IC >
IC100 6-713-717-01 IC CXD9927R-A
IC501 9-885-183-86 IC TAS5352A (See Note 2)
IC502 9-885-183-86 IC TAS5352A (See Note 2)
IC503 9-885-183-86 IC TAS5352A (See Note 2)
************************************************************
9-885-183-82 MIC BOARD, COMPLETE
*******************
************************************************************
0 9-885-183-66 POWER BOARD, COMPLETE (450V)
(E3, E12, E93)
0 9-885-183-68 POWER BOARD, COMPLETE (400V)
(CEL, RU, SAF, EA, SP1, TH)
**********************
< FUSE >
0 F901 9-885-183-87 FUSE (T 5 AL/250 V)
< VARISTOR >
0 TVR902 9-885-183-67 VDR (450V) (E3, E12, E93)
0 TVR902 9-885-183-69 VDR (400V) (CEL, RU, SAF, EA, SP1, TH)
0 TVR903 9-885-183-67 VDR (450V) (E3, E12, E93)
0 TVR903 9-885-183-69 VDR (400V) (CEL, RU, SAF, EA, SP1, TH)
************************************************************
9-885-183-81 POWER KEY BOARD, COMPLETE
(Included in complete PANEL, SWITCH board)
**************************
************************************************************
The components identifi ed by mark 9 con-
tain confi dential information.
Strictly follow the instructions whenever the
components are repaired and/or replaced.
FUNCTION KEY MAIN MIC
POWER POWER KEY
RU : Russian model
SAF : South African model
SP1 : Asian and Oceanian models
(Except Australian, Thai)
TH : Thai model
Note 1: As for parts described in this ELECTRICAL PARTS LIST, the
exchange with single part is possible. When parts other than
these are damaged, exchange the complete mounted board.
Note 2: When the complete MAIN board or IC501, IC502 and IC503
on the MAIN board are replaced, refer to “NOTE OF RE-
PLACING THE IC501, IC502 AND IC503 ON THE MAIN
BOARD AND THE COMPLETE MAIN BOARD” on page 4.
Ver. 1.4
Note 3: Refer to the “CHANGES TO SPECIFICATIONS” on page 4
for how to distinguish new/former types of the MAIN board.
(E3 and E93 models only)
To Next Page
