Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E280/T28
86
C5956 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5957 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5958 1-125-777-11 CERAMIC CHIP 0.1uF 10% 10V
C5959 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5965 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C5967 1-124-779-00 ELECT CHIP 10uF 20% 16V
C5975 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C5976 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C5977 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C5978 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C5979 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C5980 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C5981 1-137-765-21 ELECT CHIP 47uF 20% 16V
* C5982 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C6001 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C6003 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6202 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6203 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6204 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6205 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6206 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6207 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6208 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6209 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6210 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6211 1-100-905-11 CERAMIC CHIP 0.001uF 10% 50V
C6212 1-127-715-11 CERAMIC CHIP 0.22uF 10% 16V
C6213 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C6216 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6220 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C6221 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
C6222 1-112-777-11 CERAMIC CHIP 0.01uF 10% 25V
* C6224 1-112-298-91 CERAMIC CHIP 1uF 10% 16V
C6225 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C6226 1-107-819-11 CERAMIC CHIP 0.022uF 10% 16V
C6502 1-100-567-81 CERAMIC CHIP 0.01uF 10% 25V
C6503 1-117-681-11 ELECT CHIP 100uF 20% 16V
C6504 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
C6505 1-128-992-21 ELECT CHIP 47uF 20% 25V
C6602 1-100-916-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR/JACK >
CN602 1-573-768-21 PIN, CONNECTOR (1.5mm) (SMD) 5P
(E280: AEP, IT, UK, AUS, MX/T28: MX)
CN701 1-821-398-31 HDMI CONNECTOR (HDMI OUT ARC)
CN1301 1-838-664-11 FFC/FPC CONNECTOR 45P
CN2460 1-820-112-51 CONNECTOR, FFC/FPC 9P
CN2470 1-794-362-51 CONNECTOR, FFC/FPC 5P
CN5102 1-573-806-21 PIN, CONNECTOR (1.5mm) (SMD) 6P
CN5301 1-794-032-21 PIN, CONNECTOR (PC BOARD) 11P
CN5302 1-691-550-11 PIN, CONNECTOR (1.5mm) (SMD) 3P
CN5701 1-821-398-31 HDMI CONNECTOR (HDMI IN 1)
CN5702 1-821-398-31 HDMI CONNECTOR (HDMI IN 2)
CN5801 1-842-489-11 JACK-USB-RJ45 (
, LAN (100))
CN5905 1-815-460-31 CONNECTOR, FFC/FPC 26P
CN5909 1-785-466-51 CONNECTOR, FFC/FPC 7P
CN6202 1-820-112-51 CONNECTOR, FFC/FPC 9P
CN6203 1-820-115-51 CONNECTOR, FFC/FPC 15P
CN6501 1-770-469-21 PIN, CONNECTOR (PC BOARD) 2P
< DIODE >
D303 6-502-248-01 DIODE KDZTR3.9B
D304 6-502-248-01 DIODE KDZTR3.9B
D601 6-502-961-01 DIODE DA2J10100L
(E280: AEP, IT, UK, AUS, MX/T28: MX)
D602 6-502-961-01 DIODE DA2J10100L
* D5703 6-503-185-01 DIODE DSR520, H3SONYF
* D5704 6-503-185-01 DIODE DSR520, H3SONYF
* D5705 6-503-185-01 DIODE DSR520, H3SONYF
* D5706 6-503-185-01 DIODE DSR520, H3SONYF
D5901 6-500-848-01 DIODE MC2840-T112-1
D6201 6-502-961-01 DIODE DA2J10100L
D6202 6-502-961-01 DIODE DA2J10100L
D6204 6-502-961-01 DIODE DA2J10100L
D6205 6-502-961-01 DIODE DA2J10100L
D6208 6-502-961-01 DIODE DA2J10100L
D6501 6-502-961-01 DIODE DA2J10100L
< FUSE >
0 F5301 1-523-132-31 FUSE (1A/50V)
0 F5302 1-523-135-31 FUSE (3.15A/32V)
0 F5303 1-523-135-31 FUSE (3.15A/32V)
0 F5305 1-523-135-31 FUSE (3.15A/32V)
< RESISTOR/FERRITE BEAD >
FB1380 1-216-864-11 SHORT CHIP 0
FB1390 1-216-864-11 SHORT CHIP 0
FB1399 1-216-864-11 SHORT CHIP 0
FB1400 1-244-161-81 METAL CHIP 2.2 5% 1/16W
FB1454 1-216-295-91 SHORT CHIP 0
FB1456 1-216-295-91 SHORT CHIP 0
FB1458 1-216-295-91 SHORT CHIP 0
FB1462 1-216-295-91 SHORT CHIP 0
FB1466 1-216-295-91 SHORT CHIP 0
FB2400 1-244-161-81 METAL CHIP 2.2 5% 1/16W
FB2481 1-216-864-11 SHORT CHIP 0
FB5710 1-400-794-21 EMI FERRITE (SMD) (1608)
< FILTER >
FL301 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL302 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL5301 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL5302 1-234-939-21 FILTER, EMI REMOVAL (SMD)
FL5701 1-234-939-21 FILTER, EMI REMOVAL (SMD)
< IC >
IC101 (Not supplied) IC CXD9998G-BB
@ IC106 6-716-695-01 IC K4B1G1646E-HCH9T
@ IC107 6-716-695-01
IC K4B1G1646E-HCH9T
@ IC206 6-716-695-01 IC K4B1G1646E-HCH9T
@ IC207 6-716-695-01 IC K4B1G1646E-HCH9T
IC303 6-715-344-01 IC MM3404A50URE
IC304 (Not supplied) IC MM3404Z11NRE
IC305 6-715-134-01 IC MM3404A33URE
IC307 (Not supplied) IC BD9329AEFJ-E2
IC308 6-714-935-01 IC TPS54225PWPR
IC309 6-714-890-01 IC MM1855AHBE
IC501 (Not supplied) IC H27U2G8F2CTR-BCR
IC601 6-716-739-01 IC BD00GC0WEFJ-SE2
(E280: AEP, IT, UK, AUS, MX/T28: MX)
IC603 6-716-739-01 IC BD00GC0WEFJ-SE2
MB-141
Note: IC101, IC304, IC307 and IC501 on the MB-141 board cannot
exchange with single. When these parts are damaged, exchange
the complete mounted board.
@ Replacement of IC106, IC107, IC206 and IC207 on the
MB-141 board used in this unit requires a special tool.
Ver. 1.1
