Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E280/T28
8787
Note: IC702, IC5301 and IC5307 on the MB-141 board cannot ex-
change with single. When these parts are damaged, exchange the
complete mounted board.
IC702 (Not supplied) IC MM3404Z11NRE
IC705 6-705-337-01 IC TK1
1150CSCL-G
IC1361 6-716-786-01 IC MM1685YNRE
IC1401 6-714-902-01 IC TPIC1391DBTRG4
IC2401 6-716-779-01 IC TPIC1405ADFDRG4
IC5301 (Not supplied) IC BD9329AEFJ-E2
IC5302 6-711-049-01 IC S-1170B33UC-OTSTFG
IC5303 6-715-134-01 IC MM3404A33URE
IC5305 6-712-613-01 IC SI-3010KM-TLS
IC5307 (Not supplied) IC BD9329AEFJ-E2
IC5701 6-716-410-01 IC TMDS261BPAGR
IC5702 6-709-888-01 IC TC7WHU04FK
IC5703 6-709-218-01 IC TC74LVX4052FT
IC5704 6-710-820-01 IC S-24CS02AFJ-TB-G
IC5705 6-716-739-01 IC BD00GC0WEFJ-SE2
IC5706 8-759-680-48 IC TC7WH157FK
IC5707 6-710-820-01 IC S-24CS02AFJ-TB-G
IC5708 6-709-218-01 IC TC74LVX4052FT
IC5901 6-600-466-01 IC TORX147L (SONY) (TV DIGITAL IN OPTICAL)
IC5905 6-712-744-01 IC TK11190CSCL-G
IC5906 8-759-596-39 IC SN74LV4052APWR
IC5907 6-710-554-01 IC PCM1808PWR
IC5908 6-705-337-01 IC TK11150CSCL-G
IC5910 6-707-853-01 IC TC74LCX541FT (EKJ)
IC6001 6-716-690-01 IC NJM2561F1-A (TE2
IC6201 A-1815-414-A IC R5F3650KBDFA (for SERVICE)
IC6203 6-713-333-01 IC PST8429UL
IC6204 6-713-333-01 IC PST8429UL
IC6205 6-716-739-01 IC BD00GC0WEFJ-SE2
IC6501 6-712-613-01 IC SI-3010KM-TLS
IC6601 6-713-362-01 IC MFI341S2164
< JACK >
J5903 1-780-853-11 JACK, PIN 2P
(AUDIO AUDIO IN)
J6001 1-794-970-11 JACK, PIN 1P (VIDEO OUT)
< COIL >
L303 1-457-995-11 INDUCTOR 10uH
L304 1-457-771-11 INDUCTOR 2.2uH
L305 1-400-789-21 INDUCTOR 2.2uH
L306 1-400-789-21 INDUCTOR 2.2uH
L5301 1-400-789-21 INDUCTOR 2.2uH
L5302 1-457-995-11 INDUCTOR 10uH
L5304 1-400-789-21 INDUCTOR 2.2uH
L5306 1-457-995-11 INDUCTOR 10uH
L6501 1-469-526-91 INDUCTOR 22uH
< CONTACT TERMINAL >
PT101 1-780-729-12 CONTACT TERMINAL
PT102 1-780-729-12 CONTACT TERMINAL
PT103 1-780-729-12 CONTACT TERMINAL
PT104 1-780-729-12 CONTACT TERMINAL
PT105 1-780-729-12 CONTACT TERMINAL
PT106 1-780-729-12 CONTACT TERMINAL
PT107 1-780-729-12 CONTACT TERMINAL
PT108 1-780-729-12 CONTACT TERMINAL
< TRANSISTOR >
Q305 6-552-430-01 TRANSISTOR DRC5114E0L
Q702 6-551-714-01 FET INK0001AC1-T112-1
Q5301 6-552-430-01 TRANSISTOR DRC5114E0L
Q5341 6-552-430-01 TRANSISTOR DRC5114E0L
Q5703 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q5704 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q5705 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q5706 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q5709 8-729-038-37 TRANSISTOR RT1N141M-TP-1
Q5902 6-551-690-01 TRANSISTOR RT3N11M-TP-1
Q6201 6-552-408-01 TRANSISTOR DSC500100L
Q6501 6-552-408-01 TRANSISTOR DSC500100L
< RESISTOR >
R102 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R103 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R106 1-218-941-81 METAL CHIP 100 5% 1/16W
R107 1-218-941-81 METAL CHIP 100 5% 1/16W
R108 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R109 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R110 1-216-864-11 SHORT CHIP 0
R116 1-216-864-11 SHORT CHIP 0
R117 1-216-864-11 SHORT CHIP 0
R118 1-216-864-11 SHORT CHIP 0
R119 1-216-864-11 SHORT CHIP 0
R206 1-218-941-81 METAL CHIP 100 5% 1/16W
R207 1-218-941-81 METAL CHIP 100 5% 1/16W
R208 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R209 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R305 1-218-953-11 METAL CHIP 1K 5% 1/16W
R307 1-218-953-11 METAL CHIP 1K 5% 1/16W
R309 1-218-953-11 METAL CHIP 1K 5% 1/16W
R314 1-216-864-11 SHORT CHIP 0
R327 1-218-953-11 METAL CHIP 1K 5% 1/16W
R330 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R331 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R332 1-208-671-11 METAL CHIP 330 0.5% 1/16W
R333 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R334 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
R335 1-208-859-81 METAL CHIP 68 0.5% 1/16W
R336 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R340 1-218-953-11 METAL CHIP 1K 5% 1/16W
R343 1-218-953-11 METAL CHIP 1K 5% 1/16W
R345 1-218-990-81 SHORT CHIP 0
R346 1-218-990-81 SHORT CHIP 0
R361 1-218-990-81 SHORT CHIP 0
R370 1-218-955-11 METAL CHIP 1.5K 5% 1/16W
R371 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R376 1-218-953-11 METAL CHIP 1K 5% 1/16W
R403 1-216-864-11 SHORT CHIP 0
R404 1-218-954-11 METAL CHIP 1.2K 5% 1/16W
R405 1-218-977-11 METAL CHIP 100K 5% 1/16W
R406 1-216-864-11 SHORT CHIP 0
R407 1-216-864-11 SHORT CHIP 0
R409 1-216-864-11 SHORT CHIP 0
R411 1-216-864-11 SHORT CHIP 0
R414 1-216-295-91 SHORT CHIP 0
R504 1-218-990-81 SHORT CHIP 0
R505 1-218-990-81 SHORT CHIP 0
R507 1-218-990-81 SHORT CHIP 0
R508 1-218-990-81 SHORT CHIP 0
R509 1-218-990-81 SHORT CHIP 0
MB-141
To Next Page
