Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E280/T28
9191
MB-141
R8069 1-218-941-81 METAL CHIP 100 5% 1/16W
R8070 1-218-941-81 METAL CHIP 100 5% 1/16W
R8073 1-218-941-81 METAL CHIP 100 5% 1/16W
R8075 1-218-933-11 METAL CHIP 22 5% 1/16W
R8076 1-218-933-11 METAL CHIP 22 5% 1/16W
R8077 1-218-933-11 METAL CHIP 22 5% 1/16W
R8078 1-218-941-81 METAL CHIP 100 5% 1/16W
R8079 1-218-941-81 METAL CHIP 100 5% 1/16W
R8080 1-218-941-81 METAL CHIP 100 5% 1/16W
R8090 1-216-295-91 SHORT CHIP 0
R8091 1-218-973-11 METAL CHIP 47K 5% 1/16W
R8092 1-218-973-11 METAL CHIP 47K 5% 1/16W
R8093 1-216-864-11 SHORT CHIP 0
R8701 1-218-953-11 METAL CHIP 1K 5% 1/16W
R8702 1-218-933-11 METAL CHIP 22 5% 1/16W
R8703 1-218-933-11 METAL CHIP 22 5% 1/16W
< COMPOSITION CIRCUIT BLOCK >
RB501 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB502 1-234-400-21 CONDUCTOR, NETWORK (1005X4)
RB1101 1-234-378-21 RES, NETWORK 10K (1005X4)
RB1102 1-234-378-21 RES, NETWORK 10K (1005X4)
RB6201 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6202 1-234-372-11 RES, NETWORK 100 (1005X4)
RB6204 1-234-372-11 RES, NETWORK 100 (1005X4)
< THERMISTOR >
TH6201 1-804-949-11 THERMISTOR, NTC (SMD)
< VIBRATOR >
X401 1-814-278-11 VIBRATOR, CRYSTAL (27MHz)
X6201 1-795-313-21 VIBRATOR, CERAMIC (8MHz)
************************************************************
A-1799-980-A POWER KEY BOARD, COMPLETE
**************************
< CAPACITOR >
C303 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< RESISTOR >
R301 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S301 1-771-410-21 SWITCH, TACTILE (\/1)
************************************************************
SPEAKER BOARD
**************
< CAPACITOR >
C401 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C402 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C403 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C404 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C405 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C406 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C407 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C408 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C451 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C452 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C453 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C454 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C455 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C456 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C457 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C458 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C459 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C460 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C461 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C462 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C463 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C464 1-114-323-11 CERAMIC CHIP 0.01uF 10% 50V
C465 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C466 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
< CONNECTOR >
* CN451 1-691-774-11 PLUG (MICRO CONNECTOR) 12P
< TERMINAL BOARD >
TB401 1-780-452-11 TERMINAL BOARD (SPEAKER) 2P
(SPEAKERS SUR L/SUR R)
TB451 1-780-840-11 TERMINAL BOARD (SPEAKER) 4P (SPEAKERS
FRONT L/FRONT R/CENTER/SUBWOOFER)
************************************************************
A-1799-983-A TUNER BOARD, COMPLETE
(E280: US, CND, PX/T28: CND)
A-1799-986-A TUNER BOARD, COMPLETE (E280: AEP, IT, UK)
A-1799-989-A TUNER BOARD, COMPLETE
(E280: AUS, MX/T28: MX)
**********************
< CAPACITOR >
C105 1-164-218-11 CERAMIC CHIP 180PF 5% 50V
C106 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C107 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C108 1-162-963-11 CERAMIC CHIP 680PF 10% 50V
C109 1-114-813-11 CERAMIC CHIP 1uF 10% 16V
C110 1-104-658-91 ELECT 100uF 20% 10V
C111 1-114-813-11 CERAMIC CHIP 1uF 10% 16V
C122 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C123 1-114-813-11 CERAMIC CHIP 1uF 10% 16V
< CONNECTOR >
CN101 1-779-275-11 CONNECTOR, FFC (LIF (NON-ZIF)) 7P
CN102 1-842-375-11 CONNECTOR, FM ANTENNA
(E280: US, CND, PX/T28: CND)
(ANTENNA FM COAXIAL 75Ω)
CN102 1-842-376-11 CONNECTOR, FM ANTENNA
(E280: AEP, IT, UK, AUS, MX/T28: MX)
(ANTENNA FM COAXIAL 75Ω)
< DIODE >
D101 6-501-579-01 DIODE MC2837
< FILTER >
FL101 1-236-711-21 FILTER, BAND PASS
POWER KEY TUNERSPEAKER
Ver. 1.1
