Sony HBD-E280 - Tuner Board Electrical Parts

Ref. No. Part No. Description Remark
HBD-E280/T28
92
< IC >
IC101 6-716-362-01 IC RS5B700-0001E2
(E280: US, CND, AUS, PX, MX/T28)
IC101 6-716-363-01 IC RS5B700-0002E2 (E280: AEP
, IT, UK)
IC104 6-715-134-01 IC MM3404A33URE
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-481-524-11 INDUCTOR 10uH
< RESISTOR >
R101 1-216-833-11 METAL CHIP 10K 5% 1/10W
R105 1-216-801-11 METAL CHIP 22 5% 1/10W
R106 1-216-801-11 METAL CHIP 22 5% 1/10W
R107 1-216-809-11 METAL CHIP 100 5% 1/10W
R108 1-216-821-11 METAL CHIP 1K 5% 1/10W
R118 1-216-809-11 METAL CHIP 100 5% 1/10W
R120 1-216-809-11 METAL CHIP 100 5% 1/10W
R122 1-216-809-11 METAL CHIP 100 5% 1/10W
R123 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R124 1-216-809-11 METAL CHIP 100 5% 1/10W
R125 1-216-864-11 SHORT CHIP 0
< VIBRATOR >
X101 1-767-317-11 VIBRATOR, CRYSTAL (32.768kHz)
*************************************************************
MISCELLANEOUS
**************
0 55 1-777-071-23 CORD, POWER (PX)
0 55 1-777-071-83 CORD, POWER (AEP, IT, MX)
0 55 1-835-068-21 CORD, POWER (AUS)
0 55 1-837-308-11 CORD, POWER-SUPPLY (US, CND)
0 55 1-837-309-21 CORD, POWER-SUPPLY (UK)
57 1-828-295-51 WIRE (FLAT TYPE) (7 CORE)
58 1-967-633-11 HARNESS (USB) (AEP, IT, UK, AUS, MX)
109 1-828-778-51 WIRE (FLAT TYPE) (26 CORE)
110 1-842-929-51 WIRE (FLAT TYPE) (15 CORE)
152 A-1750-926-A LOADING FOR SERVICE
0 156 8-820-445-04 OPTICAL PICK-UP BLOCK (KEM-470AAA/C2RP)
157 1-838-606-51 WIRE (FLAT TYPE) (9 CORE)
158 1-838-604-51 WIRE (FLAT TYPE) (45 CORE)
159 1-828-292-51 WIRE (FLAT TYPE) (5 CORE)
M1 1-855-032-11 FAN, D.C.
SWR1 1-474-270-11 REGULATOR, SWITCHING (EDPS-170AF B)
(EXCEPT PX, MX)
SWR1 1-474-271-11 REGULATOR, SWITCHING (EDPS-170AF C)
(PX, MX)
Ver. 1.1
TUNER
