5
HBD-E280/T28
A-1815-452-A DISPLAY BOARD, COMPLETE
(E280: US, CND, AUS, PX, MX/T28)
A-1815-453-A DISPLAY BOARD, COMPLETE (E280: AEP, IT, UK)
***********************
4-257-156-01 HOLDER, FL
< CAPACITOR >
C01 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C02 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C04 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C05 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C06 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
C07 1-124-584-00 ELECT 100uF 20% 10V
C08 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C10 1-163-037-11 CERAMIC CHIP 0.022uF 10% 50V
C13 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C14 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C15 1-119-772-91 ELECT 47uF 20% 35V
C17 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C18 1-137-710-91 CERAMIC CHIP 10uF 20% 6.3V
C20 1-163-021-91 CERAMIC CHIP 0.01uF 10% 50V
C25 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C26 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C27 1-125-837-91 CERAMIC CHIP 1uF 10% 6.3V
C30 1-112-746-11 CERAMIC CHIP 4.7uF 10% 6.3V
C31 1-162-970-11 CERAMIC CHIP 0.01uF 10% 25V
C40 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
C43 1-100-566-91 CERAMIC CHIP 0.1uF 10% 25V
< CONNECTOR >
CN02 1-779-552-21 CONNECTOR, FFC (LIF (NON-ZIF)) 15P
< DIODE >
D02 6-501-579-01 DIODE MC2837
D03 6-501-579-01 DIODE MC2837
D05 6-503-014-01 DIODE DZ2J05100L
D06 6-502-961-01 DIODE DA2J10100L
< IC >
IC01 6-715-344-01 IC MM3404A50URE
IC02 6-701-729-01 IC PT6315
IC03 6-712-427-01
IC 74AHCT04PW-118
IC30 6-600-665-01 IC GP1UE27XK0VF
< JUMPER RESISTOR >
JW11 1-216-296-11 SHORT CHIP 0
< COIL >
L01 1-421-967-21 INDUCTOR 100uH
L02 1-421-967-21 INDUCTOR 100uH
< FLUORESCENT INDICATOR TUBE >
ND01 1-483-324-11 VACUUM FLUORESCENT DISPLAY
(E280: AEP, IT, UK)
ND01 1-483-324-21 VACUUM FLUORESCENT DISPLAY
(E280: US, CND, AUS, PX, MX/T28)
< TRANSISTOR >
Q01 8-729-038-42 TRANSISTOR RT1N441M-TP-1
Q02 6-551-460-01 FET RSR025P03TL
Q03 6-550-065-01 TRANSISTOR CPH5504-TL-E
Q04 6-552-408-01 TRANSISTOR DSC500100L
< RESISTOR >
R01 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R02 1-216-821-11 METAL CHIP 1K 5% 1/10W
R04 1-216-821-11 METAL CHIP 1K 5% 1/10W
R05 1-216-841-11 METAL CHIP 47K 5% 1/10W
R06 1-216-826-11 METAL CHIP 2.7K 5% 1/10W
R13 1-216-833-11 METAL CHIP 10K 5% 1/10W
R14 1-216-805-11 METAL CHIP 47 5% 1/10W
R17 1-216-805-11 METAL CHIP 47 5% 1/10W
R22 1-216-844-11 METAL CHIP 82K 5% 1/10W
R23 1-216-809-11 METAL CHIP 100 5% 1/10W
R24 1-216-809-11 METAL CHIP 100 5% 1/10W
R25 1-216-809-11 METAL CHIP 100 5% 1/10W
R26 1-216-853-11 METAL CHIP 470K 5% 1/10W
R27 1-216-845-11 METAL CHIP 100K 5% 1/10W
R28 1-216-295-91 SHORT CHIP 0
R29 1-216-813-11 METAL CHIP 220 5% 1/10W
R30 1-216-805-11 METAL CHIP 47 5% 1/10W
R31 1-216-813-11 METAL CHIP 220 5% 1/10W
R32 1-216-813-11 METAL CHIP 220 5% 1/10W
R40 1-216-809-11 METAL CHIP 100 5% 1/10W
R41 1-216-821-11 METAL CHIP 1K 5% 1/10W
R42 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R43 1-216-809-11 METAL CHIP 100 5% 1/10W
R44 1-216-821-11 METAL CHIP 1K 5% 1/10W
R45 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
< SWITCH >
S40 1-771-410-21 SWITCH, TACTILE (VOLUME +)
S41 1-771-410-21 SWITCH, TACTILE (N)
S42 1-771-410-21 SWITCH, TACTILE (Z)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
3. ELECTRICAL PARTS LIST
DISPLAY
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
• Abbreviation
AUS : Australian model
CND : Canadian model
IT : Italian model
MX : Mexican model
