HBD-E2100/E3100/E3200/E4100/E6100
69
Pin No. Pin Name I/O Description
P247 SPDIF I/O SPDIF digital audio output
P248 DVCC12_K_7 - 1.2V Digital Power
P249 AVDD12_1 - 1.2 V Power Pin
P250 RSTI I Front-End Power on reset
P251 VDAC0 O Output of General DAC
P252 VWDC2O O Output Voltage 2 of Laser Diode Control in APC
P253 VWDC3O O Output Voltage 3 of Laser Diode Control in APC
P254 FVREF O Output of Voltage Reference
P255 FPDOCD I Laser Power Monitor Input for CD APC / Differential negative input
P256 FPDODVD I Laser Power Monitor Input for DVD APC / Differential positive input
P257 EPAD - DGND
Ver. 1.5
