HBD-E2100/E3100/E3200/E4100/E6100
68
Pin No. Pin Name I/O Description
P195 UARXD I/O
Reserved for debug-only Uart pins.
(1) 1st RS232 RX
(2) T8032 RS232 RX
P196 AMUTE I UPG_STATUS
P197 HTPLG I/O HDMI Hot Plug
P198 DVCC33_IO_STB_2 - 3.3V Digital IO Power for Stand-By Module
P199 HDMISD I/O HDMI I2C data
P200 HDMISCK I/O HDMI I2C clock
P201 CEC I/O HDMI CEC
P202 LED1 I JIG_MODE0
P203 LED0 I JIG_MODE1
P204 USB_DM_P2 I/O USB port2 differential serial data bus (minus)
P205 USB_DP_P2 I/O USB port2 differential serial data bus (plus)
P206 USB_VRT_P2 - USB port2 reference resistor
P207 AVDD33_USB_P2 - 3.3V Analog Power for USB port2
P208 AVSS33_BG - BG Analog Ground
P209 REXT O External reference resistor
P210 AVDD33_COM - PLL / BG 3.3 V Analog Power
P211 TXVN_1 I/O Ethernet RD -
P212 TXVP_1 I/O Ethernet RD +
P213 TXVN_0 I/O Ethernet TD -
P214 TXVP_0 I/O Ethernet TD +
P215 AVDD33_LD - 3.3 V power for standby
P216 DVCC12_K_6 - 1.2V Digital Power
P217 AVDD33_HDMI - 3.3 V Analog Power
P218 CLK_M O HDMI TX clock differential pair (M)
P219 CLK_P O HDMI TX clock differential pair (P)
P220 CH0_M O HDMI TX data 0 differential pair (M)
P221 CH0_P O HDMI TX data 0 differential pair (P)
P222 CH1_M O HDMI TX data 1 differential pair (M)
P223 CH1_P O HDMI TX data 1 differential pair (P)
P224 CH2_M O HDMI TX data 2 differential pair (M)
P225 CH2_P O HDMI TX data 2 differential pair (P)
P226 AVDD12_HDMI_C - 1.2 V Analog Power
P227 AVDD12_HDMI_D - 1.2 V Analog Power
P228 AVSS12_HDMI - 1.2V Analog Ground
P229 NS_XTALI - 3.3V power for standby
P230 NS_XTALO I 27MHz Crystal In
P231 AVDD33_PLLGP - 3.3 V Analog Power for PLL Group
P232 AVDD33_VDAC_BG - 3.3V Analog Power
P233 AVDD33_VDAC_X - 3.3V Analog Power
P234 VDACX_OUT O DAC output
P235 VMID_PWMDAC - PWMDAC internal LDO reference
P236 AVDD33_DAC - 3.3 V Analog Power
P237 AL0 I I2S Master Clock line
P238 AVSS33_DAC - Analog Ground
P239 AR0 I I2S Bit Clock line
P240 DVCC33_IO_7 - 3.3V Digital IO power
P241 SPDIF_IN0 I Microphone signal input
P242 AOLRCK I/O Audio output left-right clock
P243 AOSDATA0 I/O Audio output serial data 0
P244 AOSDATA1 I/O Audio output serial data 1
P245 AOSDATA2 I/O Audio output serial data 2
P246 AOSDATA3 I/O Audio output serial data 3
Ver. 1.5
