HBD-E2100/E3100/E3200/E4100/E6100
67
Pin No. Pin Name I/O Description
P144 RDQ20 I/O Memory data bit 20
P145 RDQ22 I/O Memory data bit 22
P146 RDQ18 I/O Memory data bit 18
P147 DDRVCCIO_8 - 1.5V Digital IO power
P148 RDQ16 I/O Memory data bit 16
P149 RDQ27 I/O Memory data bit 27
P150 RDQ25 I/O Memory data bit 25
P151 RDQ29 I/O Memory data bit 29
P152 RDQ31 I/O Memory data bit 31
P153 RDQM3 O Memory data mask bit 3
P154 DDRVCCK_4 - 1.2V Digital Power
P155 DDRVREF I Memory VREF
P156 DDRVCCIO_9 - 1.5V Digital IO Power
P157 RDQS2 I/O Memory positive data strobe bit 2
P158 RDQS2_ I/O Memory negative data strobe bit 2
P159 RCLK1_ O Memory clock 1 negative
P160 RCLK1 O Memory clock 1 positive
P161 DDRVCCIO_A - 1.5V Digital IO Power
P162 RDQM2 O Memory data mask bit 2
P163 RDQS3 I/O Memory positive data strobe bit 3
P164 RDQS3_ I/O Memory negative data strobe bit 3
P165 RDQ28 I/O Memory data bit 28
P166 RDQ30 I/O Memory data bit 30
P167 RDQ26 I/O Memory data bit 26
P168 RDQ24 I/O Memory data bit 24
P169 RDQ17 I/O Memory data bit 17
P170 DDRVCCIO_B - 1.5V Digital IO power
P171 RDQ19 I/O Memory data bit 19
P172 RDQ23 I/O Memory data bit 23
P173 RDQ21 I/O Memory data bit 21
P174 DDRVCCK_5 - 1.2V Digital Power
P175 DVCC12_K_5 - 1.2V Digital Power
P176 AVDD33_LDO - Line driver 3.3V analog power
P177 AVDD12_LDO - 1.2 V standby power
P178 OPWRSB I/O Power Control
P179 GPIO8 I/O ICE1_TDO
P180 GPIO7 I/O ICE1_TCK
P181 GPIO6 I/O ICE1_TMS
P182 GPIO5 I/O ICE1_TDI
P183 GPIO4 - Not used
P184 DVCC33_IO_STB_1 - 3.3V Digital IO Power for Stand-By Module
P185 GPIO3 I/O WOL_INT
P186 GPIO2 I/O START_BIT
P187 GPIO1 I/O XIF_CS
P188 GPIO0 I IF_SDI
P189 VCLK - IF_SCK
P190 VSTB I SYS_REQ
P191 VDATA O IF_SDO
P192 IR I SIRCS
P193 RESET_ I Power on reset
P194 UATXD I/O
Reserved for debug-only Uart pins.
(1) 1st RS232 TX
(2) T8032 RS232 TX
Ver. 1.5
