HBD-E2100/E3100/E3200/E4100/E6100
75
Pin No. Pin Name I/O Description
50 STA516_XPDN O DAMP Driver Standby Control
51 TAS5538_XRST O Reset signal output to the DAMP processor "L": reset
52 TAS5538_XMUTE O Muting on/off control signal output to DAMP processor "L": muting on
53 NO_USE - No used
54 NO_USE - No used
55 NO_USE - No used
56 NO_USE - No used
57 MIC_CLK I/O Clock signal output terminal
58 MIC_DATA I/O Serial data output terminal
59 NO_USE - No used
60 VCC2 - Power supply terminal (+3.3V)
61 NJU72341_POWER O Power control for MIC IC
62 VSS - Ground terminal
63 PLUG_DET / MIC_IN I Microphone plug insert detection signal input terminal "H": Microphone plug insert.
64 NO_USE - No used
65
DRIVE_SD / POWER_
DET
I Shut down signal input from the power ampli er "L": detect
66 BD_TEMP I Temperature detection signal input terminal
67 STA516_TH_WARN I Thermal warning for temperature of the IC STA516 more than 130 °C
68 FL_CS O Chip select signal output to the uorescent indicator tube driver
69 ASEL0 O Audio selection signal output terminal
70 ASEL1 O Audio selection signal output terminal
71 WOL_WLAN I WOL wake up detect port input from BD decoder “H”: detect
72 NFC_RFDET I RF signal input from the NFC module “H”: detect
73 ST_RDS_INT I RDS interrupt signal input from the FM receiver
74 NAND_RESET O Reset signal output to the NAND ash "L": reset
75 BD_SDI (IF_SDO) O Serial data output to the BD decoder
76 BD_SDO (IF_SDI) I Serial data input from the BD decoder
77 BD_SCLK I Serial data transfer clock signal input from the BD decoder
78 BD_CS O Chip select signal output to the BD decoder
79 NFC_DATA I/O Serial DATA input / output with the NFC module
80 NFC_SPICLK O Serial interface clock output to the NFC module
81 BD_RESET O
Reset signal output to the BD decoder and EEPROM "L": reset
82 JIG MODE1 I/O Jig mode selection signal input from the BD decoder
83 OPWRSB I Power control signal input from the BD decoder
84 FE_EJECT O Eject key input detection signal output to the BD decoder
85 UPG_STATUS I UPG status signal input from the BD decoder
86 NO_USE - No used
87 KEY2_EJ I Key input terminal
88 KEY1_EJ I Key input terminal
89 KEY0 I Power key input terminal
90 NO_USE - No used
91 MODEL I Model setting terminal Fixed at "L" in this unit
92 DESTINATION I Destination setting
93 PCONT_WOL_STANDBY O Power Control for WOL / WOW function
94 AVSS - Ground terminal
95 NO_USE - No used
96 VREF I Reference voltage (+3.3V) input terminal
97 AVCC - Power supply terminal (+3.3V)
98 NFC_SEL O
Data transfer direction and data transfer completion noti cation signal output to the NFC
module
99 PVDD_VOL_SEL O No used
100 NO_USE - No used
Ver. 1.5
