Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E2100/E3100/E3200/E4100/E6100
88
IC201 6-716-462-01 IC BD00GA3WEFJ-E2
IC203 (Not supplied) IC TPS54295PWPR
IC204 (Not supplied) IC TPS54295PWPR
IC205 6-719-190-01 IC RT7256ALZSP
IC403 6-709-888-01 IC TC7WHU04FK
IC406 6-720-030-01 IC TPS2065CDBVR
IC408 6-718-999-01 IC MM1839A50NRE
IC520 6-718-188-01 IC BD80GA3WEFJ-E2
IC601 (Not supplied) IC TPIC2060ADFDRG4
IC701 1-843-541-11 OPTICAL RECEIVER JACK
(TV DIGITAL IN OPTICAL)
IC703 8-759-596-39 IC SN74LV4052APWR
IC704 6-710-554-01 IC PCM1808PWR
IC706 (Not supplied) IC RN5B701-0001 (EXCEPT AEP, UK)
IC706 (Not supplied) IC RN5B701-0002 (AEP, UK)
IC710 6-719-070-01 IC MM3411A50URE
IC801 (Not supplied) IC R5F3650KCDFB
IC803 6-713-333-01 IC PST8429UL
IC804 6-719-061-01 IC MM1839A33NRE
IC805 6-719-061-01 IC MM1839A33NRE
IC1001 (Not supplied) IC H27U2G8F2CTR-BCR
< JACK >
J702 1-854-005-11 JACK, PIN (2P) (AUDIO IN L/R)
< COIL >
L201 1-460-358-11 INDUCTOR 2.2uH
L202 1-460-358-11 INDUCTOR 2.2uH
L203 1-400-789-21 INDUCTOR 2.2uH
L204 1-400-789-21 INDUCTOR 2.2uH
L205 1-400-792-21 INDUCTOR 22uH
L206 1-400-789-21 INDUCTOR 2.2uH
L207 1-457-874-11 INDUCTOR 10uH
L208 1-460-358-11 INDUCTOR 2.2uH
L209 1-460-358-11 INDUCTOR 2.2uH
L702 1-414-467-31 INDUCTOR 22nH
L703 1-414-851-21 INDUCTOR 47nH
L704 1-414-851-21 INDUCTOR 47nH
L707 1-414-467-31 INDUCTOR 22nH
< TRANSISTOR >
Q201 6-552-936-01 TR LTC014EUBFS8TL
Q202 6-552-936-01 TR LTC014EUBFS8TL
Q203 6-552-936-01 TR LTC014EUBFS8TL
Q204 6-553-007-01 TR PMG85XP
Q205 6-553-007-01 TR PMG85XP
Q206 6-553-007-01 TR PMG85XP
Q207 6-552-936-01 TR LTC014EUBFS8TL
Q208 6-552-892-01 TR LSCR523UBFS8TL
Q401 6-551-346-01 TRANSISTOR LSK3541FS8T2L
Q404 6-552-936-01 TR LTC014EUBFS8TL
Q405 6-553-007-01 TR PMG85XP
Q701 6-552-936-01 TR LTC014EUBFS8TL (SP, RU)
Q702 6-552-217-01 TR RTM001P02T2L (SP, RU)
Q703 6-550-978-01 TR RN1902
Q801 6-552-892-01 TR LSCR523UBFS8TL
Q803 6-553-296-01 TR RSM002P03T2L
Q804 6-552-936-01 TR LTC014EUBFS8TL
< RESISTOR >
0 R101 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R103 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R105 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R106 1-218-941-11 METAL CHIP 100 5% 1/16W
R107 1-218-941-11 METAL CHIP 100 5% 1/16W
R108 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R109 1-208-668-11 METAL CHIP 240 0.5% 1/16W
R110 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R111 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R112 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R113 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R114 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R115 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R116 1-208-683-11 METAL CHIP 1K 0.5% 1/16W
R117 1-218-933-11 METAL CHIP 22 5% 1/16W
R118 1-218-933-11 METAL CHIP 22 5% 1/16W
R203 1-218-953-11 METAL CHIP 1K 5% 1/16W
R204 1-208-695-11 METAL CHIP 3.3K 0.5% 1/16W
* R209 1-250-499-11 METAL CHIP 1.5K 1% 1/16W
R210 1-218-957-11 METAL CHIP 2.2K 5% 1/16W
R211 1-218-971-81 METAL CHIP 33K 5% 1/16W
R212 1-218-971-81 METAL CHIP 33K 5% 1/16W
R215 1-218-971-81 METAL CHIP 33K 5% 1/16W
R216 1-218-971-81 METAL CHIP 33K 5% 1/16W
R217 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R218 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R219 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R226 1-218-953-11 METAL CHIP 1K 5% 1/16W
R228 1-208-713-11 METAL CHIP 18K 0.5% 1/16W
R229 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R230 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R231 1-208-699-11 METAL CHIP 4.7K 0.5% 1/16W
R236 1-218-973-11 METAL CHIP 47K 5% 1/16W
R237 1-218-971-81 METAL CHIP 33K 5% 1/16W
R243 1-208-715-11 METAL CHIP 22K 0.5% 1/16W
R244 1-208-933-11 METAL CHIP 82K 0.5% 1/16W
R245 1-218-974-11 METAL CHIP 56K 5% 1/16W
R246 1-208-923-11 METAL CHIP 33K 0.5% 1/16W
R247 1-218-953-11 METAL CHIP 1K 5% 1/16W
R248 1-218-953-11 METAL CHIP 1K 5% 1/16W
R249 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R252 1-208-675-11 METAL CHIP 470 0.5% 1/16W
R256 1-218-853-11 METAL CHIP 1.8K 0.5% 1/10W
R258 1-208-909-11 METAL CHIP 8.2K 0.5% 1/16W
R259 1-208-927-11 METAL CHIP 47K 0.5% 1/16W
R260 1-208-911-11 METAL CHIP 10K 0.5% 1/16W
R263 1-216-791-11 METAL CHIP 3.3 5% 1/10W
R264 1-218-966-11 METAL CHIP 12K 5% 1/16W
R268 1-208-905-11 METAL CHIP 5.6K 0.5% 1/16W
R269 1-208-931-11 METAL CHIP 68K 0.5% 1/16W
R274 1-218-953-11 METAL CHIP 1K 5% 1/16W
R275 1-218-953-11 METAL CHIP 1K 5% 1/16W
R276 1-218-941-11 METAL CHIP 100 5% 1/16W
R304 1-218-965-11 METAL CHIP 10K 5% 1/16W
R305 1-218-965-11 METAL CHIP 10K 5% 1/16W
R306 1-218-965-11 METAL CHIP 10K 5% 1/16W
R307 1-218-941-81 METAL CHIP 100 5% 1/16W
R308 1-218-941-81 METAL CHIP 100 5% 1/16W
R316 1-218-977-11 METAL CHIP 100K 5% 1/16W
MB1002
Note: IC203, IC204, IC601, IC706, IC801 and IC1001 on the
MB1002 board cannot exchange with single. When these
parts on the MB1002 board are damaged, exchange the
entire mounted board.
