Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HBD-E2100/E3100/E3200/E4100/E6100
91
Note 2: Wires (fl at type) for service is all straight.
Please bend it referring go “HOW TO BEND FFC” on
page 14 when you install it in the unit.
CN51 1-564-721-11 PIN, CONNECTOR (SMALL TYPE) 5P
CN52 1-819-866-11 USB CONNECTOR (A) (
)
< DIODE >
D01 6-503-605-01 DI UDZVTE-172.0B
D02 6-500-400-01 DIODE BAV99-215
D03 6-500-400-01 DIODE BAV99-215
D04 6-503-040-01 DI DZ2J300M0L
D05 6-503-891-01 DI 1L0353B14E0MKT01
D06 6-503-890-01 DI 1L0353W34A0MKT01
< IC >
IC01 6-600-665-01 IC GP1UE27XK0VF
IC02 6-719-198-01 IC MM3411A33URE
IC03 6-719-197-01 IC MM3411Z41URE
< JUMPER RESISTOR >
JR02
1-216-296-11 SHORT CHIP 0
JR03 1-216-296-11 SHORT CHIP 0
JR04 1-216-296-11 SHORT CHIP 0
JR05 1-216-296-11 SHORT CHIP 0
JR06 1-216-296-11 SHORT CHIP 0
JR07 1-216-295-91 SHORT CHIP 0
JR08 1-216-296-11 SHORT CHIP 0
JR09 1-216-296-11 SHORT CHIP 0
JR10 1-216-296-11 SHORT CHIP 0
JR11 1-216-296-11 SHORT CHIP 0
< FLUORESCENT INDICATOR TUBE >
ND01 1-483-460-11 VACUUM FLUORESCENT DISPLAY
< TRANSISTOR >
Q01 6-553-291-01 TR BC817DPN
Q02 6-552-892-01 TR LSCR523UBFS8TL
Q03 6-552-892-01 TR LSCR523UBFS8TL
< RESISTOR >
R01 1-216-809-11 METAL CHIP 100 5% 1/10W
R02 1-216-821-11 METAL CHIP 1K 5% 1/10W
R03 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R04 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R05 1-216-809-11 METAL CHIP 100 5% 1/10W
R06 1-216-821-11 METAL CHIP 1K 5% 1/10W
R07 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R08 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R09 1-216-805-11 METAL CHIP 47 5% 1/10W
R10 1-216-813-11 METAL CHIP 220 5% 1/10W
R11 1-216-813-11 METAL CHIP 220 5% 1/10W
R12 1-216-813-11 METAL CHIP 220 5% 1/10W
R13 1-216-839-11 METAL CHIP 33K 5% 1/10W
R14 1-216-809-11 METAL CHIP 100 5% 1/10W
R15 1-216-809-11 METAL CHIP 100 5% 1/10W
R16 1-216-809-11 METAL CHIP 100 5% 1/10W
R17 1-218-285-11 METAL CHIP 75 5% 1/10W
R18 1-218-285-11 METAL CHIP 75 5% 1/10W
R19 1-216-839-11 METAL CHIP 33K 5% 1/10W
R20 1-216-797-11 METAL CHIP 10 5% 1/10W
R21 1-216-797-11 METAL CHIP 10 5% 1/10W
R22 1-216-821-11 METAL CHIP 1K 5% 1/10W
R24 1-216-833-11 METAL CHIP 10K 5% 1/10W
R26 1-216-813-11 METAL CHIP 220 5% 1/10W
R28 1-216-833-11 METAL CHIP 10K 5% 1/10W
R29 1-216-813-11 METAL CHIP 220 5% 1/10W
R30 1-216-813-11 METAL CHIP 220 5% 1/10W
< SWITCH >
S01 1-762-875-21 SWITCH, TACTILE (N)
S02 1-762-875-21 SWITCH, TACTILE (x)
S03 1-762-875-21 SWITCH, TACTILE (FUNCTION)
S04 1-762-875-21 SWITCH, TACTILE (.)
S05 1-762-875-21 SWITCH, TACTILE (Z)
S06 1-762-875-21 SWITCH, TACTILE (VOL –)
S07 1-762-875-21 SWITCH, TACTILE (VOL +)
S08 1-762-875-21 SWITCH, TACTILE (>)
************************************************************
POWER KEY BOARD
****************
< CAPACITOR >
* C41 1-118-360-11 CERAMIC CHIP 0.1uF 10% 25V
< RESISTOR >
R41 1-216-809-11 METAL CHIP 100 5% 1/10W
< SWITCH >
S41 1-762-875-21 SWITCH, TACTILE (\/1)
************************************************************
MISCELLANEOUS
**************
52 1-846-378-51 WIRE (FLAT TYPE) (8 CORE)
55 1-968-687-12 HARNESS (USB)
56 1-458-601-11 CARD, WLAN/BT COMBO
57 1-846-376-61 WIRE (FLAT TYPE) (21 CORE) (SP, RU)
57 1-846-377-61 WIRE (FLAT TYPE) (15 CORE) (EXCEPT SP, RU)
58 1-969-958-11 HARNESS (USB)
105 1-846-375-51 WIRE (FLAT TYPE) (24 CORE)
0 107 1-834-966-41 POWER-SUPPLY CORD
(AEP, E3, E51, SAF, SP, E32, RU, MX6, PX)
0 107 1-835-068-21 CORD, POWER (AUS)
0 107 1-837-308-11 CORD, POWER-SUPPLY (US, CND)
0 107 1-837-312-11 CORD, POWER-SUPPLY (AR)
0 107 1-837-345-11 CORD, POWER-SUPPLY (TW)
0 107 1-837-822-21 CORD, POWER-SUPPLY (CH)
0 107 1-839-012-11 CORD, POWER-SUPPLY (E12)
0 107 1-839-940-21 POWER-SUPPLY CORD (TH)
0 107 1-839-999-21 POWER-SUPPLY CORD (UK, EA)
0 108 1-785-504-21 ADAPTOR, CONVERSION (E51, PX, E32, MX6)
0 109 1-770-019-71 ADAPTOR, CONVERSION PLUG 3P
(E2100: SP for Hong Kong model)
202 A-1850-153-D LOADING FOR SERVICE (BPX-7)
0 205 8-820-452-07 DEVICE, OPTICAL KEM480AAA/C2RP2
206 1-846-349-61 WIRE (FLAT TYPE) (9 CORE)
207 1-846-347-11 FLEXIBLE FLAT CABLE (45 CORE)
208 1-846-348-61 WIRE (FLAT TYPE) (5 CORE)
0 M1 1-855-244-11 DC FAN
0 SWR1 1-798-453-11 SWITCHING REGULATOR (3L392W-1)
(US, CND, AEP, UK, SAF, SP, TW, AUS, TH, CH)
PANEL POWER KEY
Note 1: When replacing the WLAN/BT COMBO card, refer to
“CHECKING METHOD OF NETWORK OPERATION”
(page 11).
