Sony HCD-BX77DBi - BASE UNIT AND OPTICAL PICK-UP DISASSEMBLY; Base Unit, Belt, and Pick-Up Removal

HCD-BX77DBi
10
2-12. LOADING MECHANISM BLOCK
2-13. BASE UNIT
4
holder (CD)
5
three screws
(BV3)
0
loading mechanism block
6
1
flexible flat cable (21 core)
(CN305)
2
flexible flat cable (5 core)
(CN311)
8
flexible flat cable (5 core)
(CN001)
7
flexible flat cable (21 core)
(CN201)
3
two screws
(BVTP2.6)
9
door CD
4 insulator
4 insulator
5 base unit
4 insulator
4 insulator
2 two cone springs
1 two floating screws (PTPWH M2.6)
1 two floating screws
(PTPWH M2.6)
1 floating screw (PTPWH M2.6)
3
loading (BK) assy
– Bottom view –
2 two cone springs
