Sony HCD-BX77DBi - DISASSEMBLY FLOW; Overall Disassembly Sequence

HCD-BX77DBi
4
SECTION 2
DISASSEMBLY
• This set can be disassembled in the order shown below.
2-1. DISASSEMBLY FLOW
2-2. PANEL (SIDE L/R)
(Page 5)
2-3. TOP PANEL BLOCK
(Page 5)
2-5. FRONT PANEL BLOCK
(Page 6)
2-12. LOADING MECHANISM
BLOCK
(Page 10)
2-13. BASE UNIT
(Page 10)
2-14. BELT
(Page 11)
2-15. OPTICAL PICK-UP BLOCK
(KSM-213DCP)
(Page 11)
2-6. REAR PANEL BLOCK
(Page 7)
2-8. AMP BOARD BLOCK
(Page 8)
2-10. MAIN BOARD
(Page 9)
2-9. POWER BOARD BLOCK
(Page 8)
2-7. PANEL (REAR)
(Page 7)
2-11. DAB BOARD,
MODULE (DAB TUNER)
(Page 9)
2-4. TOP KEY BOARD,
IP BOARD, PANEL TOP (IP)
(Page 6)
SET
