Sony HCD-BX77DBi - LOADING MECHANISM SECTION; Loading Mechanism Exploded View and Components

48
HCD-BX77DBi
6-6. LOADING MECHANISM SECTION
251 A-1242-967-B LOADING (BK) ASSY
252 3-080-478-01 BELT
253 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING
254 4-156-130-01 SPRING, CONE
255 4-229-005-41 INSULATOR
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
base unit section
255
255
253
255
253
255
254
251
254
252
not supplied
(MOTOR board)
not supplied
not supplied
