Sony HCD-BX77DBi - AMPLIFIER AND POWER BOARD DISASSEMBLY; AMP and Power Board Removal

HCD-BX77DBi
8
2-8. AMP BOARD BLOCK
2-9. POWER BOARD BLOCK
1
flexible flat cable (7 core)
(AMP board: CN308/MAIN board: CN309)
4
two screws
(BV3)
5
AMP board block
3
connector (CN320)
2
connector (CN312)
3
screw
(BV3)
5
coating clip
4
lug wire
6
four screws (BV SUMITITE S 4
u
8)
1
connector (CN904)
2
power cord connector (CN901)
7
POWER board block
