50
HCD-BX77DBi
SECTION 7
ELECTRICAL PARTS LIST
5VREG BOARD
************
< CAPACITOR >
C373 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C380 1-165-908-11 CERAMIC CHIP 1uF 10% 10V
< DIODE >
D305 6-501-582-01 DIODE 1N4002-B5
< IC >
0 IC306 6-713-031-01 IC KIA7805API-U/PF
< RESISTOR >
R401 1-216-817-1
1 METAL
CHIP 470 5% 1/10W
R437 1-216-797-11 METAL CHIP 10 5% 1/10W
************************************************************
9VREG BOARD
************
< CAPACITOR >
C325 1-126-933-11 ELECT 100uF 20% 16V
C335 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< IC >
0 IC305 6-713-032-01 IC KIA7809API-U/PF
************************************************************
AMP BOARD
**********
< CAPACITOR >
C501 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C502 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C503 1-126-947-11 ELECT 47uF 20% 35V
C504 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C505 1-162-927-11 CERAMIC CHIP 100PF 5% 50V
C506 1-126-947-11 ELECT 47uF 20% 35V
C511 1-126-964-11 ELECT 10uF 20% 50V
C512 1-126-964-11 ELECT 10uF 20% 50V
C515 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C518 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C519 1-126-925-91 ELECT 470uF 20% 10V
C521 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C522 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C523 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C524 1-162-915-11 CERAMIC CHIP 10PF 0.5PF 50V
C525 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C526 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C527 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C528 1-162-966-11 CERAMIC CHIP 0.0022uF 10% 50V
C529 1-126-948-11 ELECT 100uF 20% 35V
< CONNECTOR >
CN308 1-568-826-11 CONNECTOR, FFC 7P
0 CN320 1-819-133-11 PIN, CONNECTOR
< EARTH TERMINAL >
EP501 1-537-771-21 TERMINAL BOARD, GROUND
EP502 1-537-771-21 TERMINAL BOARD, GROUND
< IC >
0 IC601 6-711-987-01 IC STK433-730-E
< RESISTOR >
R501 1-216-817-1
1 METAL CHIP 470 5% 1/10W
R502 1-216-841-11 METAL CHIP 47K 5% 1/10W
R503 1-216-821-11 METAL CHIP 1K 5% 1/10W
R504 1-216-841-11 METAL CHIP 47K 5% 1/10W
R505 1-216-841-11 METAL CHIP 47K 5% 1/10W
R506 1-216-817-11 METAL CHIP 470 5% 1/10W
R507 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R508 1-216-821-11 METAL CHIP 1K 5% 1/10W
R509 1-216-841-11 METAL CHIP 47K 5% 1/10W
R510 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R512 1-216-821-11 METAL CHIP 1K 5% 1/10W
R513 1-216-821-11 METAL CHIP 1K 5% 1/10W
R514 1-216-821-11 METAL CHIP 1K 5% 1/10W
R515 1-216-864-11 SHORT CHIP 0
R516 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R517 1-216-837-11 METAL CHIP 22K 5% 1/10W
R518 1-216-837-11 METAL CHIP 22K 5% 1/10W
R519 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R521 1-216-817-11 METAL CHIP 470 5% 1/10W
R522 1-216-817-11 METAL CHIP 470 5% 1/10W
R523 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R524 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
0 R542 1-260-087-91 CARBON 100 5% 1/2W F
R543 1-216-853-11 METAL CHIP 470K 5% 1/10W
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
9VREG AMP5VREG
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
The components identifi ed by mark 0
or dotted line with mark 0 are critical for
safety.
Replace only with part number specifi ed.
