Sony HCD-BX77DBi - PANEL DISASSEMBLY; Side and Top Panel Removal

HCD-BX77DBi
5
Note: Follow the disassembly procedure in the numerical order given.
2-2. PANEL (SIDE L/R)
2-3. TOP PANEL BLOCK
1
two screws
(BVTP S3
u
6)
1
two screws
(BVTP S3
u
6)
2
screw
(BVTP3
u
10)
2
screw
(BVTP3
u
10)
3
panel (side L)
3
panel (side R)
1
screw
(BVTT3
u
6)
1
screw
(BVTT3
u
6)
3
five screws
(BVTP3
u
10)
4
5
connector
(CN325)
6
connector
(CN322)
7
top panel block
2
screw
(PWH3
u
6)
2
screw
(PWH3
u
6)
