Sony HCD-BX77DBi - ELECTRICAL PARTS LIST - MAIN BOARD CONT.; Main Board Parts List Continued

Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
HCD-BX77DBi
5555
IC304 6-712-055-01 IC BD3499FV-E2
IC307 6-713-032-01 IC KIA7809API-U/PF
IC310 6-702-038-11 IC PST3628NR
IC311 8-759-598-69 IC BA6956AN
IC312 8-759-430-37 IC MC14052BDTR2
< TERMINAL BOARD >
J302 1-780-275-11 TERMINAL BOARD, PUSH (4P)
< JUMPER RESISTOR >
JR101 1-216-864-11 SHORT CHIP 0
JR201 1-216-864-11 SHORT CHIP 0
JR211 1-216-864-11 SHORT CHIP 0
JR213 1-216-864-11 SHORT CHIP 0
JR214 1-216-864-11 SHORT CHIP 0
JR219 1-216-864-11 SHORT CHIP 0
JR221 1-216-864-11 SHORT CHIP 0
JR222 1-216-864-11 SHORT CHIP 0
JR223 1-216-864-11 SHORT CHIP 0
JR301 1-216-864-11 SHORT CHIP 0
JR302 1-216-296-11 SHORT CHIP 0
JR303 1-216-864-11 SHORT CHIP 0
JR304 1-216-864-11 SHORT CHIP 0
JR305 1-216-864-11 SHORT CHIP 0
JR306 1-216-864-11 SHORT CHIP 0
JR307 1-216-864-11 SHORT CHIP 0
JR308 1-216-864-11 SHORT CHIP 0
JR309 1-216-864-11 SHORT CHIP 0
JR312 1-216-864-11 SHORT CHIP 0
JR313 1-216-864-11 SHORT CHIP 0
JR314 1-216-864-11 SHORT CHIP 0
JR315 1-216-864-11 SHORT CHIP 0
JR316 1-216-864-11 SHORT CHIP 0
JR317 1-216-864-11 SHORT CHIP 0
JR318 1-216-296-11 SHORT CHIP 0
JR319 1-216-296-11 SHORT CHIP 0
JR320 1-216-864-11 SHORT CHIP 0
JR321 1-216-296-11 SHORT CHIP 0
JR322 1-216-296-11 SHORT CHIP 0
JR323 1-216-864-11 SHORT CHIP 0
JR324 1-216-864-11 SHORT CHIP 0
JR325 1-216-864-11 SHORT CHIP 0
JR326 1-216-864-11 SHORT CHIP 0
JR327 1-216-864-11 SHORT CHIP 0
JR328 1-216-864-11 SHORT CHIP 0
JR329 1-216-296-11 SHORT CHIP 0
JR330 1-216-864-11 SHORT CHIP 0
JR331 1-216-864-11 SHORT CHIP 0
JR332 1-216-864-11 SHORT CHIP 0
JR333 1-216-864-11 SHORT CHIP 0
JR334 1-216-864-11 SHORT CHIP 0
JR335 1-216-864-11 SHORT CHIP 0
JR336 1-216-864-11 SHORT CHIP 0
JR337 1-216-864-11 SHORT CHIP 0
JR340 1-216-864-11 SHORT CHIP 0
JR341 1-216-864-11 SHORT CHIP 0
JR342 1-216-296-11 SHORT CHIP 0
JR343 1-216-296-11 SHORT CHIP 0
JR344 1-216-296-11 SHORT CHIP 0
JR345 1-216-296-11 SHORT CHIP 0
JR498 1-216-864-11 SHORT CHIP 0
< COIL >
L101 1-422-009-13 COIL, AIR-CORE
L201 1-422-009-13 COIL, AIR-CORE
< TRANSISTOR >
Q103 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q203 6-550-889-01 TRANSISTOR 2SC5938-T112-1B
Q301 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q302 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q303 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q304 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q305 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q306 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q307 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q309 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q312 8-729-038-28 TRANSISTOR RT1N441C-TP-1
Q313 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q315 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q316 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q317 8-729-037-03 TRANSISTOR KTA1266GR-AT
Q319 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q320 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q333 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q338 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q340 8-729-038-23 TRANSISTOR RT1N141C-TP-1
Q341 8-729-027-38 TRANSISTOR DTA144EKA-T146
Q342 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
Q343 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q344 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q345 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q347 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q348 8-729-120-28 TRANSISTOR 2SC1623-L5L6
Q390 8-729-028-54 TRANSISTOR KTC3205
Q392 8-729-036-86 TRANSISTOR KTC3203Y-AT
Q393 6-551-696-01 TRANSISTOR ISA1235AC1TP-1EF
< RESISTOR >
R101 1-216-825-11 METAL CHIP 2.2K 5% 1/10W
R102 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R104 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R105 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R106 1-216-841-11 METAL CHIP 47K 5% 1/10W
R109 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R110 1-216-837-11 METAL CHIP 22K 5% 1/10W
R117 1-216-841-11 METAL CHIP 47K 5% 1/10W
R119 1-216-845-11 METAL CHIP 100K 5% 1/10W
R120 1-216-845-11 METAL CHIP 100K 5% 1/10W
R121 1-216-845-11 METAL CHIP 100K 5% 1/10W
R122 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R123 1-218-879-11 METAL CHIP 22K 0.5% 1/10W
R124 1-216-837-11 METAL CHIP 22K 5% 1/10W
R125 1-216-837-11 METAL CHIP 22K 5% 1/10W
R126 1-216-837-11 METAL CHIP 22K 5% 1/10W
R128 1-216-821-11 METAL CHIP 1K 5% 1/10W
R129 1-216-793-11 METAL CHIP 4.7 5% 1/10W
R130 1-216-793-11 METAL CHIP 4.7 5% 1/10W
MAIN
