SERVICE MANUAL
SUPPLEMENT-1
HCD-BX77DBi
AEP Model
UK Model
Ver. 1.1 2010.08
9-889-832-81
In this set, to correspond to new model iPod, the IP board has been changed in the
midway of production.
Only printed wiring board, schematic diagram, electrical parts list and specifi cations of
new type have been described in this supplement-1.
Refer to original service manual for other information.
Subject: Change of IP board to corresponded for new iPod series
1. NEW/FORMER DISCRIMINATION
Distinguish by the serial No. described in the model number label on the rear side.
Serial No. after it changes
AEP model : 5100859 or larger
UK model : 6123118 or larger
– Rear View –
File this supplement with the service manual.
