5
HCD-BX77DBi
4. ELECTRICAL PARTS LIST
A-1788-743-A IP BOARD, COMPLETE
******************
< CAPACITOR >
C101 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C102 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C103 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C104 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C105 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C108 1-165-989-11 CERAMIC CHIP 10uF 10% 6.3V
C109 1-128-392-11 ELECT CHIP 470uF 20% 6.3V
C111 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C114 1-128-004-11 ELECT CHIP 10uF 20% 16V
C115 1-128-004-11 ELECT CHIP 10uF 20% 16V
C118 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C119 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C120 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C121 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
< CONNECTOR >
CN101 1-766-382-21 PIN, CONNECTOR (1.5mm) (SMD) 10P
CN102 1-820-701-11 PIN, CONNECTOR 30P (iPod)
< DIODE >
D102 8-719-071-34 DIODE RB521S-30-TE61
D104 8-719-071-34 DIODE RB521S-30-TE61
D105 8-719-071-34 DIODE RB521S-30-TE61
< IC >
IC101 (Not supplied) IC R5F21246SNFP
IC102 6-702-302-01 IC
TK11133CSCL-G
IC103 6-707-593-01 IC PST3641UL
< TRANSISTOR >
Q102 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q103 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q104 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q105 6-551-750-01 TRANSISTOR 2SD2114KT146W
Q106 8-729-038-30 TRANSISTOR RT1P141M-TP-1
Q107 8-729-038-23 TRANSISTOR RT1N141C-TP-1
< RESISTOR >
R101 1-216-809-11 METAL CHIP 100 5% 1/10W
R102 1-216-809-11 METAL CHIP 100 5% 1/10W
R103 1-216-841-11 METAL CHIP 47K 5% 1/10W
R104 1-216-809-11 METAL CHIP 100 5% 1/10W
R105 1-216-833-11 METAL CHIP 10K 5% 1/10W
R106 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R107 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R108 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R109 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R110 1-218-895-11 METAL CHIP 100K 0.5% 1/10W
R111 1-218-892-11 METAL CHIP 75K 0.5% 1/10W
R112 1-218-903-11 METAL CHIP 220K 0.5% 1/10W
R113 1-218-907-11 METAL CHIP 330K 0.5% 1/10W
R114 1-216-809-11 METAL CHIP 100 5% 1/10W
R115 1-216-809-11 METAL CHIP 100 5% 1/10W
R117 1-216-839-11 METAL CHIP 33K 5% 1/10W
R118 1-216-864-11 SHORT CHIP 0
R122 1-216-833-11 METAL CHIP 10K 5% 1/10W
R128 1-216-809-11 METAL CHIP 100 5% 1/10W
R129 1-216-809-11 METAL CHIP 100 5% 1/10W
R130 1-216-809-11 METAL CHIP 100 5% 1/10W
R131 1-216-809-11 METAL CHIP 100 5% 1/10W
R132 1-216-833-11 METAL CHIP 10K 5% 1/10W
R135 1-216-833-11 METAL CHIP 10K 5% 1/10W
R136 1-216-809-11 METAL CHIP 100 5% 1/10W
R137 1-216-809-11 METAL CHIP 100 5% 1/10W
R138 1-216-809-11 METAL CHIP 100 5% 1/10W
R139 1-216-845-11 METAL CHIP 100K 5% 1/10W
R140 1-216-845-11 METAL CHIP 100K 5% 1/10W
R141 1-216-821-11 METAL CHIP 1K 5% 1/10W
R142 1-216-821-11 METAL CHIP 1K 5% 1/10W
R143 1-216-821-11 METAL CHIP 1K 5% 1/10W
R144 1-216-821-11 METAL CHIP 1K 5% 1/10W
R146 1-216-833-11 METAL CHIP 10K 5% 1/10W
R147 1-216-845-11 METAL CHIP 100K 5% 1/10W
R148 1-216-845-11 METAL CHIP 100K 5% 1/10W
R149 1-216-809-11 METAL CHIP 100 5% 1/10W
R150 1-216-833-11 METAL CHIP 10K 5% 1/10W
R153 1-216-821-11 METAL CHIP 1K 5% 1/10W
R154 1-216-833-11 METAL CHIP 10K 5% 1/10W
R156 1-216-833-11 METAL CHIP 10K 5% 1/10W
< VIBRATOR >
X101 1-795-375-11 VIBRATOR, CERAMIC (20MHz)
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
When indicating parts by reference num-
ber, please include the board name.
Note:
• Due to standardization, replacements in
the parts list may be different from the
parts specifi ed in the diagrams or the com-
ponents used on the set.
• -XX and -X mean standardized parts, so
they may have some difference from the
original one.
• Items marked “*” are not stocked since
they are seldom required for routine ser-
vice. Some delay should be anticipated
when ordering these items.
• RESISTORS
All resistors are in ohms.
METAL: Metal-fi lm resistor.
METAL OXIDE: Metal oxide-fi lm resistor.
F: nonfl ammable
• CAPACITORS
uF: μF
• COILS
uH: μH
• SEMICONDUCTORS
In each case, u: μ, for example:
uA. . : μA. . , uPA. . , μPA. . ,
uPB. . : μPB. . , uPC. . , μPC. . ,
uPD. . : μPD. .
IP
Note: IC101 cannot exchange with single. When this
part is damaged, exchange the complete IP board.
Ver. 1.2
