Sony HCD-CL1 - Printed Wiring Boards - Driver Section; Driver Section PWB Layout

2929
HCD-CL1/CL3
7-7. PRINTED WIRING BOARD BD SECTION
• See page 21 for Circuit Boards Location.
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
Ref. No. Location
D101 B-3
IC101 C-3
IC102 B-2
IC103 D-2
Q101 C-1
Q102 A-3
• Semiconductor
Location
(Page 25)
IC103
IC101
IC102
I
(A-MAX.3)
