46
HCD-CL1/CL3
SECTION 8
EXPLODED VIEWS
NOTE:
• -XX, -X mean standardized parts, so they may
have some differences from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• The mechanical parts with no reference number
in the exploded views are not supplied.
• Hardware (# mark) list and accessories and
packing materials are given in the last of this parts
list.
• Color Indication of Appearance Parts Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑ ↑
Parts of Color Cabinet’s Color
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
• Abbreviation
AUS : Australian model
MX : Mexican model
TW : Taiwan model
KR : Korea model
8-1. SIDE PANEL, BACK PANEL SECTION
#1
#1
#1
#1
#1
#1
#1
#1
#2
#2
#2
#2
not
supplied
not
supplied
not
supplied
FRONT PANEL
1
2
3
15
15
18
13
4
8
9
10
11
14
2
6
15
5
7
#1
not
supplied
not
supplied
not
supplied
not
supplied
#1
#1
#1
not
supplied
12
To Next Page
