Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
53
SECTION 9
ELECTRICAL PARTS LIST
HCD-CL1/CL3
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
• Abbreviation
AUS : Australian model
MX : Mexican model
TW : Taiwan model
KR : Korea model
AMP
A-4475-414-A AMP BOARD, COMPLETE (CL1:US)
***************************
A-4475-422-A AMP BOARD, COMPLETE (CL1:AEP,UK)
*******************************
A-4475-438-A AMP BOARD, COMPLETE (CL1:AUS,TW,KR)
**********************************
A-4475-447-A AMP BOARD, COMPLETE (CL3:AEP,UK)
*******************************
A-4475-459-A AMP BOARD, COMPLETE (CL3:KR)
***************************
A-4476-988-A AMP BOARD, COMPLETE (CL1:E,MX)
*****************************
A-4726-254-A AMP BOARD, COMPLETE (CL3:MX)
***************************
< CAPACITOR >
C801 1-128-582-11 ELECT 10uF 20% 100V
(CL1:US)
C801 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT CL1:US)
C802 1-162-286-31 CERAMIC 220PF 10% 50V
C803 1-162-282-31 CERAMIC 100PF 10% 50V
C804 1-126-965-11 ELECT 22uF 20% 50V
C805 1-136-161-00 FILM 0.047uF 5% 50V
C806 1-136-161-00 FILM 0.047uF 5% 50V
C807 1-136-153-00 FILM 0.01uF 5% 50V
(CL1:AEP,UK/CL3:AEP,UK)
C808 1-136-153-00 FILM 0.01uF 5% 50V
(CL1:AEP,UK/CL3:AEP,UK)
C809 1-162-306-11 CERAMIC 0.01uF 30% 16V
(CL1:AEP,UK/CL3:AEP,UK)
C810 1-162-306-11 CERAMIC 0.01uF 30% 16V
(CL1:AEP,UK/CL3:AEP,UK)
C811 1-107-713-11 ELECT 4.7uF 20% 50V
(CL1)
C811 1-107-721-11 ELECT 4.7uF 20% 100V
(CL3)
C832 1-104-665-11 ELECT 100uF 20% 10V
C833 1-126-961-11 ELECT 2.2uF 20% 50V
C834 1-104-665-11 ELECT 100uF 20% 10V
C851 1-128-582-11 ELECT 10uF 20% 100V
(CL1:US)
C851 1-126-964-11 ELECT 10uF 20% 50V
(EXCEPT CL1:US)
C852 1-162-286-31 CERAMIC 220PF 10% 50V
C853 1-162-282-31 CERAMIC 100PF 10% 50V
C854 1-126-965-11 ELECT 22uF 20% 50V
C855 1-136-161-00 FILM 0.047uF 5% 50V
C856 1-136-161-00 FILM 0.047uF 5% 50V
C857 1-136-153-00 FILM 0.01uF 5% 50V
(CL1:AEP,UK/CL3:AEP,UK)
C858 1-136-153-00 FILM 0.01uF 5% 50V
(CL1:AEP,UK/CL3:AEP,UK)
C859 1-162-306-11 CERAMIC 0.01uF 30% 16V
(CL1:AEP,UK/CL3:AEP,UK)
C861 1-107-713-11 ELECT 4.7uF 20% 50V
(CL1)
C861 1-107-721-11 ELECT 4.7uF 20% 100V
(CL3)
C891 1-126-959-11 ELECT 0.47uF 20% 50V
C951 1-137-844-11 ELECT 2200uF 20% 42V
(CL1:US,AEP,UK)
C951 1-135-832-11 ELECT 2200uF 20% 50V
(CL1:E,MX,AUS,TW,KR)
C951 1-135-928-11 ELECT 2200uF 20% 63V
(CL3:AEP,UK,MX,KR/CL3:AEP,UK,KR)
C952 1-137-844-11 ELECT 2200uF 20% 42V
(CL1:US,AEP,UK)
C952 1-135-832-11 ELECT 2200uF 20% 50V
(CL1:E,MX,AUS,TW,KR)
C952 1-135-928-11 ELECT 2200uF 20% 63V
(CL3:AEP,UK,MX,KR/CL3:AEP,UK,KR)
C953 1-136-165-00 FILM 0.1uF 5% 50V
C954 1-136-165-00 FILM 0.1uF 5% 50V
C957 1-136-153-00 FILM 0.01uF 5% 50V
C958 1-136-153-00 FILM 0.01uF 5% 50V
C971 1-126-965-11 ELECT 22uF 20% 50V
(CL1)
C971 1-128-560-11 ELECT 22uF 20% 100V
(CL3)
C972 1-126-965-11 ELECT 22uF 20% 50V
(CL1)
C972 1-128-560-11 ELECT 22uF 20% 100V
(CL3)
C973 1-104-665-11 ELECT 100uF 20% 10V
C974 1-126-967-11 ELECT 47uF 20% 50V
C975 1-162-306-11 CERAMIC 0.01uF 30% 16V
(CL1:AEP,UK/CL3:AEP,UK)
C991 1-126-963-11 ELECT 4.7uF 20% 50V
(CL3)
< CONNECTOR >
CN801 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
CN952 1-778-982-21 CONNECTOR, BOARD TO BOARD 13P
< DIODE >
D801 8-719-911-19 DIODE 1SS133T-72
D831 8-719-911-19 DIODE 1SS133T-72
D851 8-719-911-19 DIODE 1SS133T-72
D881 8-719-911-19 DIODE 1SS133T-72
D891 8-719-911-19 DIODE 1SS133T-72
To Next Page
