HCD-CL1/CL3
7-15. PRINTED WIRING BOARD PANEL SECTION
(Page 25)
CD
SYNC
REC
EDIT
DBFB
VIDEO
IC 702
Ref. No. Location
D701 B-8
D702 E-4
D703 E-4
D712 G-6
D741 H-7
D743 H-6
D745 H-5
D746 E-8
D771 B-5
D772 C-5
D773 B-5
D774 C-5
D775 B-5
D776 B-4
D777 B-4
D778 B-5
D779 C-5
IC702 C-8
Q701 B-7
Q702 B-2
Q741 F-8
Q742 F-6
Q743 F-8
Q744 E-7
Q745 F-7
Q746 F-7
• Semiconductor
Location
• See page 21 for Circuit Boards Location.
There are a few cases that the part printed on
this diagram isn’t mounted in this model.
