Sony HCD-CL1 - Electrical Parts List - AMP Components; AMP Section Resistors and Transistors

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
54
HCD-CL1/CL3
AMP
The components identified by mark 0 or
dotted line with mark 0 are critical for safety.
Replace only with part number specified.
D953 8-719-024-99 DIODE 11ES2-NTA2B
D954 8-719-024-99 DIODE 11ES2-NTA2B
D955 8-719-024-99 DIODE 11ES2-NTA2B
D956 8-719-024-99 DIODE 11ES2-NTA2B
D957 8-719-024-99 DIODE 11ES2-NTA2B
D958 8-719-024-99 DIODE 11ES2-NTA2B
D959 8-719-024-99 DIODE 11ES2-NTA2B
D960 8-719-024-99 DIODE 11ES2-NTA2B
D961 8-719-911-19 DIODE 1SS133T-72
D962 8-719-911-19 DIODE 1SS133T-72
D971 8-719-911-19 DIODE 1SS133T-72
D991 8-719-911-19 DIODE 1SS133T-72 (CL3)
< IC >
IC801 8-749-016-93 IC STK402-070S (CL1)
IC801 8-749-016-96 IC STK402-120S (CL3)
< COIL >
L801 1-420-872-00 COIL, AIR-CORE (CL1:AEP,UK/CL3:AEP,UK)
L851 1-420-872-00 COIL, AIR-CORE (CL1:AEP,UK/CL3:AEP,UK)
< TRANSISTOR >
Q801 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL1)
Q801 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (CL3)
Q831 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q832 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q833 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q834 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q835 8-729-119-76 TRANSISTOR 2SA1175TP-HFE (CL1)
Q835 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA (CL3)
Q836 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL1)
Q836 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (CL3)
Q837 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL1)
Q837 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (CL3)
Q841 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q842 8-729-119-78 TRANSISTOR 2SC2785TP-HFE
Q851 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL1)
Q851 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (CL3)
Q881 8-729-119-76 TRANSISTOR 2SA1175TP-HFE (CL1)
Q881 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA (CL3)
Q882 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL1)
Q882 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (CL3)
Q971 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL1)
Q971 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (CL3)
Q972 8-729-140-82 TRANSISTOR 2SA988TP-PAFAEA
Q973 8-729-119-78 TRANSISTOR 2SC2785TP-HFE (CL1)
Q973 8-729-140-84 TRANSISTOR 2SC1841TP-PAFAEA (CL3)
< RESISTOR >
R801 1-249-417-11 CARBON 1K 5% 1/4W F
R802 1-249-437-11 CARBON 47K 5% 1/4W
R803 1-249-419-11 CARBON 1.5K 5% 1/4W F
(CL1)
R803 1-249-416-11 CARBON 820 5% 1/4W F
(CL3)
R804 1-249-437-11 CARBON 47K 5% 1/4W
0R805 1-233-352-11 ENCAPSULATED COMPONENT (CL1)
0R805 1-234-499-21 ENCAPSULATED COMPONENT (CL3)
R806 1-260-076-11 CARBON 10 5% 1/2W
R807 1-260-076-11 CARBON 10 5% 1/2W
(CL1:AEP,UK/CL3:AEP,UK)
R808 1-260-076-11 CARBON 10 5% 1/2W
(CL1:AEP,UK/CL3:AEP,UK)
R810 1-249-417-11 CARBON 1K 5% 1/4W F
R811 1-249-431-11 CARBON 15K 5% 1/4W
R812 1-249-441-11 CARBON 100K 5% 1/4W
R813 1-249-437-11 CARBON 47K 5% 1/4W
(CL3)
R814 1-249-438-11 CARBON 56K 5% 1/4W
R815 1-249-433-11 CARBON 22K 5% 1/4W
R816 1-215-889-00 METAL OXIDE 330 5% 2W
(CL1)
R816 1-216-455-11 METAL OXIDE 560 5% 2W
(CL3)
R833 1-249-425-11 CARBON 4.7K 5% 1/4W F
R834 1-249-435-11 CARBON 33K 5% 1/4W
R835 1-249-433-11 CARBON 22K 5% 1/4W
R836 1-249-429-11 CARBON 10K 5% 1/4W
R837 1-249-429-11 CARBON 10K 5% 1/4W
R839 1-249-441-11 CARBON 100K 5% 1/4W
R841 1-249-440-11 CARBON 82K 5% 1/4W
(CL1:US,AEP,UK,AUS,TW,KR)
R841 1-249-441-11 CARBON 100K 5% 1/4W
(CL1:E,MX/CL3)
R842 1-249-441-11 CARBON 100K 5% 1/4W
R843 1-249-441-11 CARBON 100K 5% 1/4W
R851 1-249-417-11 CARBON 1K 5% 1/4W F
R852 1-249-437-11 CARBON 47K 5% 1/4W
R853 1-249-419-11 CARBON 1.5K 5% 1/4W F
(CL1)
R853 1-249-416-11 CARBON 820 5% 1/4W F
(CL3)
R854 1-249-437-11 CARBON 47K 5% 1/4W
0R855 1-233-352-11 ENCAPSULATED COMPONENT (CL1)
0R855 1-234-499-21 ENCAPSULATED COMPONENT (CL3)
R856 1-260-076-11 CARBON 10 5% 1/2W
R857 1-260-076-11 CARBON 10 5% 1/2W
(CL1:AEP,UK/CL3:AEP,UK)
R858 1-260-076-11 CARBON 10 5% 1/2W
(CL1:AEP,UK/CL3:AEP,UK)
R860 1-249-417-11 CARBON 1K 5% 1/4W F
R861 1-249-431-11 CARBON 15K 5% 1/4W
R862 1-249-441-11 CARBON 100K 5% 1/4W
R863 1-249-437-11 CARBON 47K 5% 1/4W
(CL3)
R864 1-249-437-11 CARBON 47K 5% 1/4W
R865 1-249-433-11 CARBON 22K 5% 1/4W
R866 1-215-889-00 METAL OXIDE 330 5% 2W
(CL1)
R866 1-216-455-11 METAL OXIDE 560 5% 2W
(CL3)
0R881 1-215-890-11 METAL OXIDE 470 5% 2W
(CL1)
0R881 1-215-892-11 METAL OXIDE 1K 5% 2W
(CL3)
R882 1-249-429-11 CARBON 10K 5% 1/4W
R883 1-249-429-11 CARBON 10K 5% 1/4W
