Sony HCD-CL1 - Parts List - Side;Back Panel Assembly; Parts for Side;Back Panel Assembly

47
HCD-CL1/CL3
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
1 4-232-226-01 SCREW, HEXAGON SOCKET TAPPING
2 3-363-099-11 SCREW (CASE 3 TP2)
3 4-231-649-01 PANEL (L), SIDE (SILVER)
(CL1:AEP,UK,AUS,E51,MX,TW,KR)
3 4-231-649-11 PANEL (L), SIDE (SILVER) (CL1:US)
3 4-231-649-21 PANEL (L), SIDE (BLACK) (CL3)
3 4-231-649-31 PANEL (L), SIDE (BLACK) (CL1:US)
4 A-4476-076-A TC BOARD, COMPLETE
5 1-769-910-11 WIRE (FLAT TYPE) (9 CORE)
6 1-693-530-81 TUNER (FM/AM) (CL1:US)
6 1-693-531-81 TUNER (FM/AM) (CL1:AUS,MX,TW/CL3:MX)
6 1-693-529-41 TUNER (FM/AM) (CL1:AEP,UK/CL3:AEP,UK)
6 1-693-537-81 TUNER (CL1:E)
6 1-693-538-81 TUNER (CL1:KR/CL3:KR)
7 1-769-944-11 WIRE (FLAT TYPE) (11 CORE)
(CL1:US,AUS,E,MX,TW,KR/CL3:MX,KR)
7 1-773-008-11 WIRE (FLAT TYPE) (15 CORE)
(CL1:AEP,UK/CL3:AEP,UK)
8 1-680-270-11 THERMAL BOARD
9 X-4953-318-1 PANEL ASSY, TOP (SILVER)
(CL1:AEP,UK,AUS,E,MX,TW,KR)
9 X-4953-349-1 PANEL ASSY, TOP (SILVER) (CL1:US)
9 X-4953-658-1 PANEL ASSY, TOP (BLACK) (CL3)
9 X-4953-663-1 PANEL ASSY, TOP (BLACK) (CL1:US)
10 4-231-656-01 PANEL, BACK (CL3:AEP,UK)
10 4-231-656-21 PANEL, BACK (CL3:KR)
10 4-231-677-01 PANEL, BACK (CL1:AEP,UK)
10 4-231-677-11 PANEL, BACK (CL1:US)
10 4-231-677-21 PANEL, BACK (CL1:MX)
10 4-231-677-31 PANEL, BACK (CL1:AUS)
10 4-231-677-71 PANEL, BACK (CL1:TW)
10 4-231-677-81 PANEL, BACK (CL1:KR)
10 4-231-656-31 PANEL, BACK (CL3:MX)
10 4-231-677-91 PANEL, BACK (CL1:E)
11 1-763-072-11 FAN, D.C. (CL3)
12 A-2100-929-A TAPE MECHANISM UNIT (TCM-230ASR41CL)
13 4-231-650-01 PANEL (R), SIDE (SILVER)
(CL1:AEP,UK,AUS,E51,MX,TW,KR)
13 4-231-650-11 PANEL (R), SIDE (SILVER) (CL1:US)
13 4-231-650-21 PANEL (R), SIDE (BLACK) (CL3)
13 4-231-650-31 PANEL (R), SIDE (BLACK) (CL1:US)
14 A-4475-419-A MAIN BOARD, COMPLETE (CL1:US)
14 A-4475-433-A MAIN BOARD, COMPLETE (CL1:AEP,UK)
14 A-4475-444-A MAIN BOARD, COMPLETE (CL1:AUS,TW,KR)
14 A-4475-450-A MAIN BOARD, COMPLETE (CL3:AEP,UK)
14 A-4475-462-A MAIN BOARD, COMPLETE (CL3:KR)
14 A-4476-083-A MAIN BOARD, COMPLETE (CL1:E,MX)
14 A-4726-257-A MAIN BOARD, COMPLETE (CL3:MX)
15 4-951-620-01 SCREW (2.6X8), +BVTP
18 1-680-258-11 VOL SEL BOARD (CL1:E,TW)
