Sony HCD-CL1 - Electrical Parts List - Driver and Back Light Components; Main Board Resistors; Driver and Back Light Components

Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
57
HCD-CL1/CL3
< CONNECTOR >
CN701 1-785-324-11 PIN, CONNECTOR (STRAIGHT) 12P
CN702 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE)2P
CN703 1-785-331-11 PIN, CONNECTOR (LIGHT ANGLE)5P
CN704 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE)3P
CN705 1-785-329-21 PIN, CONNECTOR (LIGHT ANGLE)3P
< IC >
IC701 8-759-598-69 IC BA6956AN
< TRANSISTOR >
Q701 8-729-029-66 TRANSISTOR RT1N141S-TP
< RESISTOR >
R701 1-249-429-11 CARBON 10K 5% 1/4W
R702 1-249-401-11 CARBON 47 5% 1/4W F
R705 1-249-435-11 CARBON 33K 5% 1/4W
R706 1-249-417-11 CARBON 1K 5% 1/4W F
R707 1-249-429-11 CARBON 10K 5% 1/4W
************************************************************
1-678-462-11 IN OUT SW BOARD
***************
< SWITCH >
S741 1-771-821-11 SWITCH, PUSH (1 KEY) (IN)
S742 1-771-821-11 SWITCH, PUSH (1 KEY) (OUT)
************************************************************
A-4475-419-A MAIN BOARD, COMPLETE (CL1:US)
****************************
A-4475-433-A MAIN BOARD, COMPLETE (CL1:AEP,UK)
********************************
A-4475-444-A MAIN BOARD, COMPLETE (CL1:AUS,TW,KR)
***********************************
A-4475-450-A MAIN BOARD, COMPLETE (CL3:AEP,UK)
********************************
A-4475-462-A MAIN BOARD, COMPLETE (CL3:KR)
****************************
A-4476-083-A MAIN BOARD, COMPLETE (CL1:E,MX)
******************************
A-4726-257-A MAIN BOARD, COMPLETE (CL3:MX)
****************************
7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
< CAPACITOR >
C103 1-126-767-11 ELECT 1000uF 20% 16V
C104 1-126-956-91 ELECT 0.1uF 20% 50V
C105 1-126-933-11 ELECT 100uF 20% 16V
C106 1-126-935-11 ELECT 470uF 20% 16V
C107 1-126-956-91 ELECT 0.1uF 20% 50V
C108 1-126-964-11 ELECT 10uF 20% 50V
C109 1-126-953-11 ELECT 2200uF 20% 35V
C110 1-126-937-11 ELECT 4700uF 20% 16V
C114 1-126-964-11 ELECT 10uF 20% 50V
C116 1-126-916-11 ELECT 1000uF 20% 6.3V
C117 1-126-916-11 ELECT 1000uF 20% 6.3V
C119 1-126-916-11 ELECT 1000uF 20% 6.3V
C120 1-126-964-11 ELECT 10uF 20% 50V
C121 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C122 1-126-935-11 ELECT 470uF 20% 16V
C141 1-126-964-11 ELECT 10uF 20% 50V
C142 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(CL1:AEP,UK/CL3:AEP,UK)
C143 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C183 1-109-889-11 ELECT 1uF 20% 50V
C191 1-126-964-11 ELECT 10uF 20% 50V
C192 1-162-960-11 CERAMIC CHIP 220PF 10% 50V
(CL1:AEP,UK/CL3:AEP,UK)
C200 1-126-964-11 ELECT 10uF 20% 50V
C201 1-104-665-11 ELECT 100uF 20% 10V
C202 1-130-477-00 MYLAR 0.0033uF 5% 50V
C203 1-126-964-11 ELECT 10uF 20% 50V
C204 1-136-165-00 FILM 0.1uF 5% 50V
C205 1-136-169-00 FILM 0.22uF 5% 50V
C206 1-130-479-00 MYLAR 0.0047uF 5% 50V
C207 1-126-964-11 ELECT 10uF 20% 50V
C208 1-136-165-00 FILM 0.1uF 5% 50V
C209 1-136-165-00 FILM 0.1uF 5% 50V
C210 1-126-963-11 ELECT 4.7uF 20% 50V
C211 1-126-964-11 ELECT 10uF 20% 50V
C212 1-126-964-11 ELECT 10uF 20% 50V
C214 1-126-964-11 ELECT 10uF 20% 50V
C218 1-126-964-11 ELECT 10uF 20% 50V
C219 1-126-964-11 ELECT 10uF 20% 50V
C253 1-126-964-11 ELECT 10uF 20% 50V
C254 1-136-165-00 FILM 0.1uF 5% 50V
C255 1-136-169-00 FILM 0.22uF 5% 50V
C256 1-130-479-00 MYLAR 0.0047uF 5% 50V
C257 1-126-964-11 ELECT 10uF 20% 50V
C258 1-136-165-00 FILM 0.1uF 5% 50V
C259 1-136-165-00 FILM 0.1uF 5% 50V
C260 1-126-963-11 ELECT 4.7uF 20% 50V
C261 1-126-964-11 ELECT 10uF 20% 50V
C262 1-126-964-11 ELECT 10uF 20% 50V
C264 1-126-964-11 ELECT 10uF 20% 50V
C301 1-126-960-11 ELECT 1uF 20% 50V
C303 1-136-165-00 FILM 0.1uF 5% 50V
C305 1-126-964-11 ELECT 10uF 20% 50V
C306 1-126-960-11 ELECT 1uF 20% 50V
C307 1-126-959-11 ELECT 0.47uF 20% 50V
C308 1-126-964-11 ELECT 10uF 20% 50V
C309 1-137-194-81 FILM 0.47uF 5% 50V
C310 1-162-962-11 CERAMIC CHIP 470PF 10% 50V
C311 1-126-964-11 ELECT 10uF 20% 50V
C312 1-126-959-11 ELECT 0.47uF 20% 50V
C313 1-162-964-11 CERAMIC CHIP 0.001uF 10% 50V
C314 1-126-964-11 ELECT 10uF 20% 50V
C315 1-126-963-11 ELECT 4.7uF 20% 50V
C316 1-126-933-11 ELECT 100uF 20% 16V
C317 1-104-665-11 ELECT 100uF 20% 10V
C319 1-126-959-11 ELECT 0.47uF 20% 50V
C321 1-126-964-11 ELECT 10uF 20% 50V
C322 1-126-964-11 ELECT 10uF 20% 50V
C351 1-126-960-11 ELECT 1uF 20% 50V
C353 1-136-165-00 FILM 0.1uF 5% 50V
C355 1-126-964-11 ELECT 10uF 20% 50V
C356 1-126-960-11 ELECT 1uF 20% 50V
IN OUT SWDRIVER MAIN
