Sony HCD-D790 - Page 15

— 15 —
2 Two screws
(BTP 2.6
× 8)
5 Hang the
two belts.
4 Removal the capstan motor
to direction of the arrow.
1 Break the soldering of
motor lead.
3 Claw
2-14. AUDIO BOARD
2-15. CAPSTAN MOTOR
2 Two rivets
3 Break the soldering of tw
o
flexible flat cables.
1 Connector
(CN651)
4 Four screws
(BTP 2.6
× 4)
5 Audio board
