Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 99 —
* 1-669-630-11 CD-A SW BOARD
**************
< DIODE >
D641 8-719-058-04 DIODE SEL5223S-TP15 (NON-STOP)
< RESISTOR >
R731 1-249-425-11 CARBON 4.7K 5% 1/4W F
R732 1-249-427-11 CARBON 6.8K 5% 1/4W F
R733 1-249-429-11 CARBON 10K 5% 1/4W
R734 1-249-432-11 CARBON 18K 5% 1/4W
R735 1-249-436-11 CARBON 39K 5% 1/4W
R736 1-247-881-00 CARBON 120K 5% 1/4W
R737 1-247-881-00 CARBON 120K 5% 1/4W
R741 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S661 1-554-303-21 SWITCH, TACTILE (DISC 1)
S662 1-554-303-21 SWITCH, TACTILE (DISC 2)
S663 1-554-303-21 SWITCH, TACTILE (DISC 3)
S664 1-554-303-21 SWITCH, TACTILE (DISC 4)
S665 1-554-303-21 SWITCH, TACTILE (DISC 5)
S666 1-554-303-21 SWITCH, TACTILE (FLASH)
S667 1-554-303-21 SWITCH, TACTILE (NON-STOP)
S668 1-554-303-21 SWITCH, TACTILE (LOOP)
************************************************************
* 1-669-631-11 CD-B1 SW BOARD
***************
< CONNECTOR >
* CN642 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D645 8-719-057-10 DIODE LNJ301MPUJAB (· CD PLAY)
D646 8-719-057-97 DIODE SEL5923A-TP15 (P PAUSE)
D647 8-719-057-10 DIODE LNJ301MPUJAB (· CD PLAY)
< RESISTOR >
R745 1-249-419-11 CARBON 1.5K 5% 1/4W F
R746 1-249-421-11 CARBON 2.2K 5% 1/4W F
R747 1-247-843-11 CARBON 3.3K 5% 1/4W
R748 1-249-425-11 CARBON 4.7K 5% 1/4W F
R749 1-247-807-31 CARBON 100 5% 1/4W
R750 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S676 1-554-303-21 SWITCH, TACTILE (·)
S677 1-554-303-21 SWITCH, TACTILE (p)
S678 1-554-303-21 SWITCH, TACTILE (P)
S679 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
************************************************************
* 1-669-632-11 CD-B2 SW BOARD
***************
< RESISTOR >
R752 1-249-427-11 CARBON 6.8K 5% 1/4W F
R753 1-249-429-11 CARBON 10K 5% 1/4W
R754 1-249-432-11 CARBON 18K 5% 1/4W
R755 1-249-436-11 CARBON 39K 5% 1/4W
R756 1-247-881-00 CARBON 120K 5% 1/4W
< SWITCH >
S681 1-554-303-21 SWITCH, TACTILE (‚)
S682 1-554-303-21 SWITCH, TACTILE (REPEAT)
S683 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
S684 1-554-303-21 SWITCH, TACTILE (1/ALL DISCS)
S685 1-554-303-21 SWITCH, TACTILE (EDIT)
S686 1-554-303-21 SWITCH, TACTILE (º)
S711 1-467-968-11 ENCODER, ROTARY (≠ AMS ±)
************************************************************
* 1-664-016-11 DOOR SW BOARD
***************
< CAPACITOR >
C691 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN661 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S691 1-771-057-11 SWITCH, PUSH (1 KEY) (6 OPEN)
************************************************************
* A-4392-452-A HEADPHONE-MIC BOARD, COMPLETE
*******************************
< CAPACITOR >
C760 1-162-306-11 CERAMIC 0.01uF 20% 16V
C761 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-162-294-31 CERAMIC 0.001uF 10% 50V
C765 1-162-215-31 CERAMIC 47PF 5% 50V
C766 1-162-290-31 CERAMIC 470PF 10% 50V
C767 1-162-215-31 CERAMIC 47PF 5% 50V
C769 1-162-282-31 CERAMIC 100PF 10% 50V
C770 1-126-961-11 ELECT 2.2uF 20% 50V
C771 1-126-959-11 ELECT 0.47uF 20% 50V
C773 1-126-964-11 ELECT 10uF 20% 50V
C774 1-126-964-11 ELECT 10uF 20% 50V
C775 1-162-294-31 CERAMIC 0.001uF 10% 50V
C776 1-162-294-31 CERAMIC 0.001uF 10% 50V
C794 1-164-159-21 CERAMIC 0.1uF 50V
C795 1-164-159-21 CERAMIC 0.1uF 50V
C797 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C798 1-164-159-21 CERAMIC 0.1uF 50V
C799 1-164-159-21 CERAMIC 0.1uF 50V
CD-A SW CD-B1 SW HEADPHONE-MICDOOR SWCD-B2 SW
