Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 100 —
< CONNECTOR >
* CN701 1-568-935-11 PIN, CONNECTOR 8P
< IC >
IC760 8-759-634-51 IC M5218AP
< JACK >
J760 1-770-226-41 JACK (LARGE TYPE) (PHONES)
J761 1-770-226-41 JACK (LARGE TYPE) (MIC)
< RESISTOR >
R760 1-249-429-11 CARBON 10K 5% 1/4W
R761 1-249-417-11 CARBON 1K 5% 1/4W F
R764 1-249-441-11 CARBON 100K 5% 1/4W
R765 1-249-417-11 CARBON 1K 5% 1/4W F
R766 1-247-863-91 CARBON 22K 5% 1/4W
R767 1-249-429-11 CARBON 10K 5% 1/4W
R769 1-247-885-00 CARBON 180K 5% 1/4W
R770 1-247-807-31 CARBON 100 5% 1/4W
< VARIABLE RESISTOR >
RV760 1-225-366-11 RES, VAR, CARBON 50K (MIC LEVEL)
************************************************************
* 1-650-669-11 LEAF SWITCH BOARD
*****************
< CONNECTOR >
* CN1001 1-568-854-11 SOCKET, CONNECTOR 11P
CN1001 1-695-372-31 PIN, CONNECTOR (PC BOARD) 11P
< TRANSISTOR >
Q1001 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
Q1002 8-749-010-90 TRANSISTOR PHOTO REFLECTOR
NJL5165KA-H
< RESISTOR >
R1001 1-247-818-11 CARBON 300 5% 1/4W
R1002 1-247-820-11 CARBON 360 5% 1/4W
R1003 1-249-414-11 CARBON 560 5% 1/4W
R1004 1-247-834-11 CARBON 1.3K 5% 1/4W
R1005 1-247-818-11 CARBON 300 5% 1/4W
< SWITCH >
S1001 1-692-832-11 SWITCH, PUSH (1 KEY) (A PLAY)
S1002 1-692-832-11 SWITCH, PUSH (1 KEY) (B PLAY)
S1004 1-571-281-21 SWITCH, LEAF (A HALF)
S1005 1-571-281-21 SWITCH, LEAF (A CrO2)
S1006 1-572-248-11 SWITCH, LEAF (REC A)
S1007 1-572-248-11 SWITCH, LEAF (B HALF)
S1008 1-571-281-21 SWITCH, LEAF (B CrO2)
S1009 1-571-281-21 SWITCH, LEAF (REC B)
************************************************************
* 1-664-017-11 LED BOARD
**********
< CONNECTOR >
CN671 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D671 8-719-058-03 DIODE SEL5423E-TP15
D672 8-719-058-03 DIODE SEL5423E-TP15
D673 8-719-058-03 DIODE SEL5423E-TP15
D674 8-719-058-03 DIODE SEL5423E-TP15
< RESISTOR >
R791 1-249-412-11 CARBON 390 5% 1/4W F
************************************************************
* A-4392-438-A MAIN BOARD, COMPLETE (D390/G5500)
*********************
* A-4392-474-A MAIN BOARD, COMPLETE (D790)
*********************
* A-4403-870-A MAIN BOARD, COMPLETE (XB60: AEP, UK)
*********************
* A-4403-890-A MAIN BOARD, COMPLETE (XB44: E, AR, MX)
*********************
* A-4403-894-A MAIN BOARD, COMPLETE (XB50: AEP, UK)
*********************
* A-4403-909-A MAIN BOARD, COMPLETE (XB33: E, AR, MX)
*********************
* A-4407-353-A MAIN BOARD, COMPLETE (XB50: EE, CIS)
*********************
* A-4407-358-A MAIN BOARD, COMPLETE (XB60: EE, CIS)
*********************
* A-4407-361-A MAIN BOARD, COMPLETE (XB44: SAF, AUS)
*********************
* A-4407-364-A MAIN BOARD, COMPLETE (XB33: SAF, AUS)
*********************
* 4-870-539-11 PLATE, GROUND
7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
< CAPACITOR >
C100 1-164-159-21 CERAMIC 0.1uF 50V
C101 1-162-288-31 CERAMIC 330PF 10% 50V
(XB50/XB60)
C102 1-162-282-31 CERAMIC 100PF 10% 50V
C103 1-162-282-31 CERAMIC 100PF 10% 50V
C104 1-126-961-11 ELECT 2.2uF 20% 50V
C105 1-162-600-11 CERAMIC 0.0047uF 30% 16V
C106 1-162-301-11 CERAMIC 0.0015uF 30% 16V
C107 1-126-956-91 ELECT 0.1uF 20% 50V
C108 1-126-967-11 ELECT 47uF 20% 10V
(XB50/XB60)
C121 1-162-286-21 CERAMIC 220PF 10% 50V
C122 1-162-286-21 CERAMIC 220PF 10% 50V
(XB33/XB44/XB50/XB60)
C123 1-162-306-11 CERAMIC 0.01uF 20% 16V
C131 1-136-495-11 FILM 0.068uF 5% 50V
(XB50/XB60)
C132 1-136-495-11 FILM 0.068uF 5% 50V
(XB50/XB60)
C133 1-164-159-21 CERAMIC 0.1uF 50V
(XB50/XB60)
