Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
ā 112 ā
C59 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C60 1-163-809-11 CERAMIC CHIP 0.047uF 10% 25V
C61 1-126-301-11 ELECT 1uF 20% 50V
C62 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C63 1-163-129-00 CERAMIC CHIP 330PF 5% 50V
C65 1-126-967-11 ELECT 47uF 20% 16V
C66 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C67 1-126-16211 ELECT 3.3uF 20% 50V
C68 1-163-031-11 CERAMIC 0.01uF 50V
C69 1-126-967-11 ELECT 47uF 20% 16V
C71 1-162-306-11 CERAMIC 0.01uF 30% 16V
C72 1-126-967-11 ELECT 47uF 20% 16V
C73 1-163-031-11 CERAMIC 0.01uF 50V
C74 1-163-031-11 CERAMIC 0.01uF 50V
C120 1-163-105-00 CERAMIC CHIP 33PF 5% 50V
C1751 1-164-159-21 CERAMIC 0.1uF 50V
C1752 1-126-967-11 ELECT 47uF 20% 16V
C1753 1-126-964-11 ELECT 10uF 20% 50V
C1754 1-162-291-31 CERAMIC 560PF 10% 50V
C1755 1-126-964-11 ELECT 10uF 20% 50V
C1756 1-126-961-11 ELECT 2.2uF 20% 50V
C1757 1-162-288-31 CERAMIC 330PF 10% 50V
C1758 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1759 1-163-135-00 CERAMIC CHIP 560PF 5% 50V
C1760 1-163-031-11 CERAMIC CHIP 0.01uF 50V
C1761 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
C1762 1-163-245-11 CERAMIC CHIP 56PF 5% 50V
C1763 1-126-961-11 ELECT 2.2uF 20% 50V
< FILTER >
CF1 1-579-374-71 FILTER, CERAMIC
CF2 1-760-393-11 FILTER, CERAMIC
CF3 1-760-393-11 FILTER, CERAMIC
< CONNECTOR >
* CN1 1-568-834-11 SOCKET, CONNECTOR 15P
< DIODE >
D21 8-719-976-99 DIODE UDZ-TE-17-5.1B
D41 8-719-016-74 DIODE 1SS352-TPH3
D42 8-719-991-33 DIODE 1SS133T-77
D1751 8-719-016-74 DIODE 1SS352-TPH3
< FRONT-END >
FE1 1-693-357-11 FRONT END (4 GANG)
FE2 1-233-514-11 ENCAPSULATED COMPONENT
< IC >
IC21 8-759-288-54 IC LC72130
IC41 8-759-495-82 IC LA1838
IC1751 8-759-634-51 IC M5218AP
IC1752 8-759-450-86 IC BU1922
< IFT >
IFT41 1-409-636-11 TRANSFORMER, IF (CERAMIC FILTER)
< JUMPER RESISTOR >
JR2 1-216-295-91 METAL CHIP 0 5% 1/10W
JR6 1-216-295-91 METAL CHIP 0 5% 1/10W
JR8 1-216-295-91 METAL CHIP 0 5% 1/10W
JR9 1-216-295-91 METAL CHIP 0 5% 1/10W
JR12 1-216-296-91 METAL CHIP 0 5% 1/8W
JR46 1-216-296-91 METAL CHIP 0 5% 1/8W
JR47 1-216-295-11 METAL CHIP 0 5% 1/10W
JR48 1-216-295-11 METAL CHIP 0 5% 1/10W
JR49 1-216-296-11 METAL CHIP 0 5% 1/8W
JR51 1-216-295-11 METAL CHIP 0 5% 1/10W
JR52 1-216-295-11 METAL CHIP 0 5% 1/10W
JR53 1-216-296-11 METAL CHIP 0 5% 1/8W
JR54 1-216-295-11 METAL CHIP 0 5% 1/10W
< COIL >
L2 1-414-142-11 MICRO INDUCTOR 1uH
L3 1-410-521-11 MICRO INDUCTOR 100uH
L4 1-410-515-11 INDUCTOR 33uH
L41 1-407-500-00 MICRO INDUCTOR 4.7mH
L1751 1-410-521-11 MICRO INDUCTOR 100uH
< FILTER >
LPF41 1-239-845-11 FILTER, LOW PASS
LPF42 1-239-845-11 FILTER, LOW PASS
< TRANSISTOR >
Q1 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q2 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q3 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q4 8-729-201-27 TRANSISTOR 2SC2715Y-TE85L
Q5 8-729-424-08 TRANSISTOR MUN2111
Q9 8-729-216-22 TRANSISTOR 2SA812-M5M6
Q11 8-729-421-22 TRANSISTOR MUN2211
Q12 8-729-421-22 TRANSISTOR MUN2211
Q13 8-729-421-22 TRANSISTOR MUN2211
Q14 8-729-421-22 TRANSISTOR MUN2211
< RESISTOR >
R1 1-249-401-11 CARBON 47 5% 1/4W F
R2 1-216-037-00 METAL CHIP 330 5% 1/10W
R3 1-216-037-00 METAL CHIP 330 5% 1/10W
R5 1-216-037-00 METAL CHIP 330 5% 1/10W
R6 1-216-081-00 METAL CHIP 22K 5% 1/10W
R7 1-216-037-00 METAL CHIP 330 5% 1/10W
R8 1-216-037-00 METAL CHIP 330 5% 1/10W
R9 1-216-081-00 METAL CHIP 22K 5% 1/10W
R10 1-216-037-00 METAL CHIP 330 5% 1/10W
R11 1-216-081-00 METAL CHIP 22K 5% 1/10W
R12 1-216-037-00 METAL CHIP 330 5% 1/10W
R13 1-216-037-00 METAL CHIP 330 5% 1/10W
R14 1-216-081-00 METAL CHIP 22K 5% 1/10W
R18 1-216-073-00 METAL CHIP 10K 5% 1/10W
R19 1-216-073-00 METAL CHIP 10K 5% 1/10W
R21 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R22 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R23 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R24 1-216-025-91 METAL CHIP 100 5% 1/10W
R25 1-249-417-11 CARBON 1K 5% 1/4W F
