Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 113 —
R26 1-249-437-11 CARBON 47K 5% 1/4W
R27 1-249-429-11 CARBON 10K 5% 1/4W
R28 1-249-417-11 CARBON 1K 5% 1/4W F
R29 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R30 1-216-186-00 METAL CHIP 330 5% 1/8W
R31 1-216-025-91 METAL CHIP 100 5% 1/10W
R32 1-249-425-11 CARBON 4.7K 5% 1/4W F
R33 1-249-425-11 CARBON 4.7K 5% 1/4W F
R34 1-249-425-11 CARBON 4.7K 5% 1/10W
R35 1-216-214-00 METAL CHIP 4.7K 5% 1/8W
R36 1-216-025-91 METAL CHIP 100 5% 1/10W
R37 1-216-073-00 METAL CHIP 10K 5% 1/10W
R38 1-216-089-91 METAL CHIP 47K 5% 1/10W
R39 1-249-429-11 CARBON 10K 5% 1/4W
R41 1-216-013-00 METAL CHIP 33 5% 1/10W
R42 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R43 1-216-037-00 METAL CHIP 330 5% 1/10W
R44 1-216-001-00 METAL CHIP 10 5% 1/10W
R45 1-247-843-11 CARBON 3.3K 5% 1/4W F
R46 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R47 1-216-097-91 METAL CHIP 100K 5% 1/10W
R48 1-249-417-11 CARBON 1K 5% 1/4W F
R49 1-216-049-91 METAL CHIP 1.0K 5% 1/10W
R50 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R51 1-216-065-00 METAL CHIP 4.7K 5% 1/10W
R52 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R53 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R54 1-216-073-00 METAL CHIP 10K 5% 1/10W
R55 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R57 1-216-162-00 METAL CHIP 33 5% 1/8W
R58 1-216-013-00 METAL CHIP 33 5% 1/10W
R91 1-216-295-91 METAL CHIP 0 5% 1/10W
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1751 1-247-807-31 CARBON 100 5% 1/4W
R1752 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1753 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1754 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1755 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1756 1-249-401-11 CARBON 47 5% 1/4W F
R1757 1-216-295-91 METAL CHIP 0 5% 1/10W
< VARIABLE RESISTOR >
RV41 1-238-600-11 RES, ADJ, CARBON 10K
RV42 1-238-600-11 RES, ADJ, CARBON 10K
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-767-825-21 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450KHz)
X1751 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
************************************************************
1-664-014-11 TRANS BOARD
************
(D390: US/D790: US/G5500/XB50/XB60)
* 1-668-169-11 TRANS BOARD
*************
(D390: CND/D790: CND/XB33/XB44)
1-533-233-21 HOLDER, FUSE (EXCEPT XB33/XB44)
1-533-399-11 HOLDER, FUSE (XB33/XB44)
1-533-903-21 HOLDER, FUSE (EXCEPT XB33/XB44)
< CAPACITOR >
C903 1-164-159-21 CERAMIC 0.1uF 50V
(XB50/XB60)
< CONNECTOR >
* CN901 1-564-522-11 PLUG, CONNECTOR 7P
CN902 1-564-513-11 PLUG, CONNECTOR 10P (D390:CND)
* CN902 1-564-518-11 PLUG, CONNECTOR 3P
(D390: US/D790/G5500/XB33/XB44/XB50/XB60)
CN903 1-535-139-00 BASE POST 14MM (10MM PITCH) 2P
(XB33: E, MX/XB44: E, MX)
CN903 1-774-108-11 PIN, CONNECTOR (PC BOARD)
(EXCEPT XB33: E, MX/XB44: E, MX)
< CONNECTOR >
! CNP901 1-558-943-51 CORD, POWER (E, MX)
! CNP901 1-575-042-21 CORD, POWER (US, CND)
! CNP901 1-575-651-21 CORD, POWER (AEP, EE, AR, CIS, SAF, UK)
! CNP901 1-696-845-11 CORD, POWER (AUS)
! CNP901 1-769-744-91 CORD, POWER (XB50/XB60)
< FUSE >
! F901 1-532-388-31 FUSE, TIME LAG (2A, 250V) (XB50)
! F901 1-532-464-31 FUSE, TIME LAG (2.5A, 250V)
(XB33: E, AR, SAF, AUS/XB44: E, AR, SAF, AUS/XB60)
! F902 1-532-505-31 FUSE, TIME LAG (2.5A, 250V)
(XB33: E, AR, MX/XB44: E, AR, MX)
! F902 1-533-310-11 FUSE, GLASS TUBE (6.3A 125V)
(D390: CND/D790: CND)
! F902 1-533-420-11 FUSE, GLASS CYLINDRICAL(DIA.5)(5A,125V)
(D390: US/D790: US/G5500)
< RESISTOR >
! R901 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(D390: CND/D790/XB33/XB44/XB60)
! R901 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(D390: US/G5500/XB50)
! R902 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
(D390: CND/D790/XB33/XB44/XB60)
! R902 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
(D390: US/G5500/XB50)
! R903 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
! R904 1-219-119-81 FUSIBLE 0.1 5% 1/4W F
R907 1-202-725-00 SOLID 3.3M 10% 1/2W
(D390: US/D790: US/G5500)
R911 1-202-725-00 SOLID 3.3M 10% 1/2W
(D390: CND/D790: CND)
TCB TRANS
Note:
The components identi-
fied by mark ! or dotted
line with mark ! are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
