Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
— 114 —
< SWITCH >
S901 1-762-753-11 SWITCH, VOLTAGE SELECTION
(VOLTAGE SELECTOR) (XB33: E, AR/XB44: E, AR)
************************************************************
**************
MISCELLANEOUS
**************
5 1-233-544-11 ENCAPSULATED COMPONENT
(D390/D790/G5500)
5 1-233-545-11 ENCAPSULATED COMPONENT (XB33/XB44)
6 1-769-974-11 WIRE (FLAT TYPE) (13 CORE)
(EXCEPT XB50/XB60)
6 1-773-006-11 WIRE (FLAT TYPE) (15 CORE) (XB50/XB60)
7 1-698-792-11 FAN, DC (XB44)
58 1-773-161-11 WIRE (FLAT TYPE) (21 CORE)
59 1-769-949-11 WIRE (FLAT TYPE) (11 CORE)
120 1-773-051-11 WIRE (FLAT TYPE) (17 CORE)
156 1-777-868-11 WIRE (FLAT TYPE) (19 CORE)
! 159 1-569-008-11 ADAPTOR, CONVERSION 2P (AR)
! 159 1-770-019-11 ADAPTOR, CONVERSION PLUG 3P (UK)
! CNP901 1-558-943-51 CORD, POWER (E, MX)
! CNP901 1-575-042-21 CORD, POWER (US, CND)
! CNP901 1-575-651-21 CORD, POWER (AEP, EE, AR, CIS, SAF, UK)
! CNP901 1-696-845-11 CORD, POWER (AUS)
HP101 1-500-093-11 HEAD, MAGNETIC (PLAYBACK) (DECKA)
HRPE1011-500-094-11 HEAD, MAGNETIC (REC/PB/ERASE) (DECK B)
M1 X-3371-223-1 MOTOR ASSY, CAPSTAN
M2 A-2004-410-A MOTTOR ASSY, DC (TRIGGER)
M101 X-4917-523-4 MOTOR ASSY (SPINDLE)
M102 X-4917-504-1 MOTOR ASSY (SLED)
M201 A-4660-977-A MOTOR ASSY (TABLE)
! T901 1-431-045-11 TRANSFORMER, POWER (D390: US/G5500)
! T901 1-431-046-11 TRANSFORMER, POWER (D790: US)
! T901 1-431-634-11 TRANSFORMER, POWER (XB50)
! T901 1-431-635-11 TRANSFORMER, POWER (XB33)
! T901 1-431-636-11 TRANSFORMER, POWER (XB60)
! T901 1-431-637-11 TRANSFORMER, POWER (XB44)
! T901 1-431-733-11 TRANSFORMER, POWER
(D390: CND/D790: CND)
************************************************************
ACCESSORIES & PACKING MATERIALS
********************************
1-475-115-11 COMMANDER, STANDARD (RM-SD70)
(made in Indonesia: AEP)
1-475-115-31 COMMANDER, STANDARD (RM-SD70)
(made in Malaysia: AEP)
1-501-374-11 ANTENNA, LOOP
1-501-659-41 ANTENNA (FM)(EXCEPT XB50/XB60)
1-501-804-11 ANTENNA (FM)(XB50/XB60)
1-775-512-21 CODE, SPEAKER CONNECTION
3-862-180-11 MANUAL, INSTRUCTION
(made in Malaysia: except AEP) (ENGLISH)
3-862-180-22 MANUAL, INSTRUCTION (Canadian) (FRENCE)
3-862-180-31 MANUAL, INSTRUCTION (E, AR, MX)
(FRENCE, SPANISH)
3-862-180-51 MANUAL, INSTRUCTION
(made in Malaysia: AEP) (GERMAN)
3-862-180-61 MANUAL, INSTRUCTION
(made in Malaysia: AEP)
(DUTCH, SWEDISH, ITALIAN)
3-862-180-71 MANUAL, INSTRUCTION
(made in Malaysia: AEP)
(FRENCE, SPANISH, PORTUGUESE)
3-862-180-81 MANUAL, INSTRUCTION (EE, CIS)
(RUSSIAN, POLISH)
3-862-181-11 MANUAL, INSTRUCTION
(made in Indonesia: AEP) (ENGLISH)
3-862-181-21 MANUAL, INSTRUCTION
(made in Indonesia: AEP)
(FRENCH, SPANISH, PORTUGUESE)
4-991-151-01 COVER, BATTERY (for RM-SD70)
************************************************************
**************
HARDWARE LIST
**************
#1 7-685-646-79 SCREW +BVTP 3 × 8 TYPE2 N-S
#2 7-685-871-01 SCREW +BVTT 3 × 6 (S)
#3 7-685-872-09 SCREW +BVTT 3 × 8 (S)
#4 7-685-650-79 SCREW +BVTP 3 × 16 TYPE2 N-S
#5 7-685-862-09 SCREW +BVTT 2.6 × 6 (S)
#6 7-685-131-19 SCREW +BTP 2.6 × 4 TYPE2 N-S
#7 7-685-533-19 SCREW +BTP 2.6 × 6 TYPE2 N-S
#8 7-621-775-10 SCREW +B 2.6 × 4
#9 7-685-534-19 SCREW +BTP 2.6 × 8 TYPE2 N-S
#10 7-623-921-01 RING, RETAINING, CAPSTAN
#11 7-621-775-00 SCREW +B 2.6 × 3
#12 7-621-255-15 SCREW +P 2 × 3
TRANS
Note:
The components identi-
fied by mark ! or dotted
line with mark ! are criti-
cal for safety.
Replace only with part
number specified.
Note:
Les composants identifiés par
une marque ! sont critiques
pour la sécurité.
Ne les remplacer que par une
piéce portant le numéro
spécifié.
HCD-D390/D790/G5500/XB33/XB44/XB50/XB60
9-922-757-11
Sony Corporation
Home A&V Products Company
98B1689-1
Printed in Japan © 1998.2
Published by General Engineering Dept.
(Shibaura)
