– 111 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
BD CD-A SW CD-B1 SW
R105 1-216-088-00 METAL CHIP 43K 5% 1/10W
R106 1-216-088-00 METAL CHIP 43K 5% 1/10W
R107 1-216-088-00 METAL CHIP 43K 5% 1/10W
R108 1-216-088-00 METAL CHIP 43K 5% 1/10W
R109 1-216-093-00 METAL CHIP 68K 5% 1/10W
R114 1-216-101-00 METAL CHIP 150K 5% 1/10W
R115 1-216-101-00 METAL CHIP 150K 5% 1/10W
R116 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R117 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R118 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R119 1-216-085-00 METAL CHIP 33K 5% 1/10W
R120 1-216-089-91 RES,CHIP 47K 5% 1/10W
R121 1-216-114-00 RES,CHIP 510K 5% 1/10W
R122 1-216-097-91 RES,CHIP 100K 5% 1/10W
R123 1-216-099-00 METAL CHIP 120K 5% 1/10W
R124 1-216-091-00 METAL CHIP 56K 5% 1/10W
R125 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R126 1-216-063-91 RES,CHIP 3.9K 5% 1/10W
R127 1-216-089-91 RES,CHIP 47K 5% 1/10W
R128 1-216-098-00 METAL CHIP 110K 5% 1/10W
R129 1-216-025-91 RES,CHIP 100 5% 1/10W
R130 1-216-079-00 METAL CHIP 18K 5% 1/10W
R131 1-216-079-00 METAL CHIP 18K 5% 1/10W
R132 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R133 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R134 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R135 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R136 1-216-073-00 METAL CHIP 10K 5% 1/10W
R137 1-216-065-91 RES,CHIP 4.7K 5% 1/10W
R138 1-216-025-91 RES,CHIP 100 5% 1/10W
R156 1-216-081-00 METAL CHIP 22K 5% 1/10W
R157 1-216-069-00 METAL CHIP 6.8K 5% 1/10W
R158 1-216-001-00 METAL CHIP 10 5% 1/10W
R159 1-216-121-91 RES,CHIP 1M 5% 1/10W
R161 1-216-097-91 RES,CHIP 100K 5% 1/10W
R162 1-216-073-00 METAL CHIP 10K 5% 1/10W
R163 1-216-121-91 RES,CHIP 1M 5% 1/10W
R164 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R165 1-216-049-91 RES,CHIP 1K 5% 1/10W
R166 1-216-073-00 METAL CHIP 10K 5% 1/10W
R167 1-216-081-00 METAL CHIP 22K 5% 1/10W
R168 1-216-073-00 METAL CHIP 10K 5% 1/10W
R169 1-216-079-00 METAL CHIP 18K 5% 1/10W
R170 1-216-081-00 METAL CHIP 22K 5% 1/10W
R171 1-216-073-00 METAL CHIP 10K 5% 1/10W
R172 1-216-079-00 METAL CHIP 18K 5% 1/10W
R173 1-216-025-91 RES,CHIP 100 5% 1/10W
R174 1-216-033-00 METAL CHIP 220 5% 1/10W
R175 1-216-025-91 RES,CHIP 100 5% 1/10W
R176 1-216-025-91 RES,CHIP 100 5% 1/10W
R177 1-216-025-91 RES,CHIP 100 5% 1/10W
R178 1-216-025-91 RES,CHIP 100 5% 1/10W
R179 1-216-025-91 RES,CHIP 100 5% 1/10W
R180 1-216-025-91 RES,CHIP 100 5% 1/10W
R181 1-216-025-91 RES,CHIP 100 5% 1/10W
R188 1-216-037-00 METAL CHIP 330 5% 1/10W
R190 1-216-097-91 RES,CHIP 100K 5% 1/10W
R191 1-216-105-91 RES,CHIP 220K 5% 1/10W
< SWITCH >
S101 1-572-085-11 SWITCH, LEAF (LIMIT)
< VIBRATOR >
X101 1-767-408-21 VIBRATOR, CRYSTAL (16.9344MHz)
**************************************************************
* 1-664-019-11 CD-A SW BOARD
*************
< DIODE >
D641 8-719-058-04 DIODE SEL5223S-TP15 (NON-STOP)
< RESISTOR >
R731 1-249-411-11 CARBON 330 5% 1/4W
R732 1-249-413-11 CARBON 470 5% 1/4W F
R733 1-249-415-11 CARBON 680 5% 1/4W F
R734 1-249-417-11 CARBON 1K 5% 1/4W F
R735 1-249-419-11 CARBON 1.5K 5% 1/4W F
R736 1-249-421-11 CARBON 2.2K 5% 1/4W F
R737 1-249-417-11 CARBON 1K 5% 1/4W F
R741 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S661 1-554-303-21 SWITCH, TACTILE (DISC 1)
S662 1-554-303-21 SWITCH, TACTILE (DISC 2)
S663 1-554-303-21 SWITCH, TACTILE (DISC 3)
S664 1-554-303-21 SWITCH, TACTILE (DISC 4)
S665 1-554-303-21 SWITCH, TACTILE (DISC 5)
S666 1-554-303-21 SWITCH, TACTILE (FLASH)
S667 1-554-303-21 SWITCH, TACTILE (NON-STOP)
S668 1-554-303-21 SWITCH, TACTILE (LOOP)
**************************************************************
* 1-664-020-11 CD-B1 SW BOARD
**************
< CONNECTOR >
* CN642 1-568-943-11 PIN, CONNECTOR 5P
< DIODE >
D645 8-719-057-29 DIODE SML78423C-TP15 (·)
D646 8-719-057-97 DIODE SEL5923A-TP15 (P)
D647 8-719-057-29 DIODE SML78423C-TP15 (·)
< RESISTOR >
R745 1-247-815-91 CARBON 220 5% 1/4W
R746 1-249-411-11 CARBON 330 5% 1/4W
R747 1-249-413-11 CARBON 470 5% 1/4W F
R748 1-249-415-11 CARBON 680 5% 1/4W F
R749 1-247-807-31 CARBON 100 5% 1/4W
R750 1-247-807-31 CARBON 100 5% 1/4W
R751 1-247-807-31 CARBON 100 5% 1/4W
