– 112 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
DOOR SWCD MOTORCD-LEDCD-B2 SW HP/MIC
< SWITCH >
S676 1-554-303-21 SWITCH, TACTILE (·)
S677 1-554-303-21 SWITCH, TACTILE (p)
S678 1-554-303-21 SWITCH, TACTILE (P)
S679 1-554-303-21 SWITCH, TACTILE (DISC SKIP)
**************************************************************
* 1-664-021-11 CD-B2 SW BOARD
**************
< RESISTOR >
R752 1-249-417-11 CARBON 1K 5% 1/4W F
R753 1-249-419-11 CARBON 1.5K 5% 1/4W F
R754 1-249-421-11 CARBON 2.2K 5% 1/4W F
R755 1-247-843-11 CARBON 3.3K 5% 1/4W
R756 1-249-427-11 CARBON 6.8K 5% 1/4W F
< SWITCH >
S681 1-554-303-21 SWITCH, TACTILE ())
S682 1-554-303-21 SWITCH, TACTILE (REPEAT)
S683 1-554-303-21 SWITCH, TACTILE (PLAY MODE)
S684 1-554-303-21 SWITCH, TACTILE (1/ALL DISCS)
S685 1-554-303-21 SWITCH, TACTILE (EDIT)
S686 1-554-303-21 SWITCH, TACTILE (0)
S711 1-467-968-11 ENCODER, ROTARY (≠ AMS ±)
**************************************************************
* 1-664-017-11 CD-LED BOARD
************
< CONNECTOR >
CN671 1-506-481-11 PIN, CONNECTOR 2P
< DIODE >
D671 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D672 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D673 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
D674 8-719-058-03 DIODE SEL5423E-TP15 (DISC TABLE)
< RESISTOR >
R791 1-249-412-11 CARBON 390 5% 1/4W F
**************************************************************
* A-4673-765-A CD MOTOR BOARD, COMPLETE
************************
* 4-980-385-01 HOLDER (SW)
< CAPACITOR >
C201 1-124-907-11 ELECT 10uF 20% 50V
C202 1-164-159-21 CERAMIC 0.1uF 50V
C203 1-124-907-11 ELECT 10uF 20% 50V
< CONNECTOR >
* CN201 1-568-947-11 PIN, CONNECTOR 9P
< IC >
IC201 8-759-365-94 IC TA8409S
< COIL >
L201 1-408-117-00 INDUCTOR 10uH
< MOTOR >
M201 A-4660-977-A MOTOR ASSY (TABLE)
< RESISTOR >
R205 1-249-427-11 CARBON 6.8K 5% 1/4W F
R206 1-249-425-11 CARBON 4.7K 5% 1/4W F
< SWITCH >
S201 1-762-587-11 SWITCH, PUSH (1 KEY)(UP)
**************************************************************
* 1-664-016-11 DOOR SW BOARD
*************
< CAPACITOR >
C691 1-164-159-21 CERAMIC 0.1uF 50V
< CONNECTOR >
CN661 1-506-481-11 PIN, CONNECTOR 2P
< SWITCH >
S691 1-771-057-11 SWITCH, PUSH (1 KEY)(6 OPEN)
**************************************************************
* A-4392-452-A HP/MIC BOARD, COMPLETE
***********************
< CAPACITOR >
C760 1-162-306-11 CERAMIC 0.01uF 20% 16V
C761 1-126-961-11 ELECT 2.2uF 20% 50V
C764 1-162-294-31 CERAMIC 0.001uF 10% 50V
C765 1-162-215-31 CERAMIC 47PF 5% 50V
C766 1-162-290-31 CERAMIC 470PF 10% 50V
C767 1-162-215-31 CERAMIC 47PF 5% 50V
C769 1-162-282-31 CERAMIC 100PF 10% 50V
C770 1-126-961-11 ELECT 2.2uF 20% 50V
C771 1-126-959-11 ELECT 0.47uF 20% 50V
C773 1-126-964-11 ELECT 10uF 20% 50V
C774 1-126-964-11 ELECT 10uF 20% 50V
C775 1-162-294-31 CERAMIC 0.001uF 10% 50V
C776 1-162-294-31 CERAMIC 0.001uF 10% 50V
C794 1-164-159-21 CERAMIC 0.1uF 50V
C795 1-164-159-21 CERAMIC 0.1uF 50V
C797 1-162-302-11 CERAMIC 0.0022uF 20% 16V
C798 1-164-159-21 CERAMIC 0.1uF 50V
C799 1-164-159-21 CERAMIC 0.1uF 50V
