– 121 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
R693 1-247-807-31 CARBON 100 5% 1/4W
R694 1-247-807-31 CARBON 100 5% 1/4W
R695 1-247-807-31 CARBON 100 5% 1/4W
R696 1-247-807-31 CARBON 100 5% 1/4W
R697 1-247-807-31 CARBON 100 5% 1/4W
R698 1-247-807-31 CARBON 100 5% 1/4W
R699 1-247-807-31 CARBON 100 5% 1/4W
R700 1-247-807-31 CARBON 100 5% 1/4W
R701 1-247-807-31 CARBON 100 5% 1/4W
R702 1-247-807-31 CARBON 100 5% 1/4W
R704 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S601 1-554-303-21 SWITCH, TACTILE (ENTER/NEXT)
S602 1-554-303-21 SWITCH, TACTILE (TUNER MEMORY)
S603 1-554-303-21 SWITCH, TACTILE (TUNING MODE)
S604 1-554-303-21 SWITCH, TACTILE (TUNER/BAND)
S605 1-554-303-21 SWITCH, TACTILE (TUNING +)
S606 1-554-303-21 SWITCH, TACTILE (TUNING -)
S607 1-554-303-21 SWITCH, TACTILE (STEREO/MONO)
S608 1-554-303-21 SWITCH, TACTILE (PTY)(AEP,UK)
S609 1-554-303-21 SWITCH, TACTILE (FUNCTION)
S610 1-554-303-21 SWITCH, TACTILE (GROOVE)
S611 1-554-303-21 SWITCH, TACTILE (GEQ 4)
S612 1-554-303-21 SWITCH, TACTILE (GEQ “)
S613 1-554-303-21 SWITCH, TACTILE (GEQ ”)
S614 1-554-303-21 SWITCH, TACTILE (GEQ $)
S615 1-554-303-21 SWITCH, TACTILE
XB80AV/XB88AV: (SUPER WOOFER), D890AV/XB55AV: (DBFB)
S616 1-554-303-21 SWITCH, TACTILE (SUPER W MODE)
(XB80AV/XB88AV)
S619 1-554-303-21 SWITCH, TACTILE (GEQ CONTROL)
S620 1-554-303-21 SWITCH, TACTILE (ENTER)
S621 1-554-303-21 SWITCH, TACTILE (EFFECT)
S622 1-554-303-21 SWITCH, TACTILE (WAVE)
S623 1-554-303-21 SWITCH, TACTILE (KARAOKE PON/MPX)
S624 1-554-303-21 SWITCH, TACTILE (DSP)
S625 1-554-303-21 SWITCH, TACTILE (PROLOGIC)
S626 1-554-303-21 SWITCH, TACTILE (P FILE MEMORY)
S627 1-554-303-21 SWITCH, TACTILE (SPECTRUM ANALYZER)
S628 1-554-303-21 SWITCH, TACTILE (DISPLAY/DEMO)
S629 1-554-303-21 SWITCH, TACTILE (POWER)
S630 1-554-303-21 SWITCH, TACTILE (t/TIMER SET)
S631 1-554-303-21 SWITCH, TACTILE (REC)
S632 1-554-303-21 SWITCH, TACTILE (DAILY 1)
S633 1-554-303-21 SWITCH, TACTILE (DAILY 2)
S634 1-554-303-21 SWITCH, TACTILE (SLEEP)
S701 1-473-392-11 ENCODER, ROTARY (VOLUME)
< VIBRATOR >
X601 1-579-125-11 VIBRATOR, CERAMIC (8MHz)
**************************************************************
* A-4407-196-A POWER BOARD, COMPLETE (XB80AV)
***********************
* A-4407-230-A POWER BOARD, COMPLETE (D890AV)
***********************
* A-4407-990-A POWER BOARD, COMPLETE (XB55AV/XB88AV)
***********************
< CAPACITOR >
C101 1-130-781-00 FILM 0.22uF 10% 100V
C102 1-130-781-00 FILM 0.22uF 10% 100V
C103 1-136-169-00 FILM 0.22uF 5% 50V
C104 1-136-169-00 FILM 0.22uF 5% 50V
C105 1-162-294-31 CERAMIC 0.001uF 10% 50V
C106 1-162-294-31 CERAMIC 0.001uF 10% 50V
C107 1-128-576-11 ELECT 100uF 20% 100V
C108 1-128-576-11 ELECT 100uF 20% 63V
C110 1-126-942-61 ELECT 1000uF 20% 25V
(XB80AV)
C110 1-104-665-11 ELECT 100uF 20% 50V
(EXCEPT XB80AV)
C151 1-128-493-11 ELECT 4700uF 20% 71V
C152 1-128-493-11 ELECT 4700uF 20% 71V
C153 1-128-550-11 ELECT 2200uF 20% 50V
C154 1-128-550-11 ELECT 2200uF 20% 50V
C201 1-128-582-11 ELECT 10uF 20% 100V
C202 1-162-292-31 CERAMIC 680PF 10% 50V
C203 1-162-286-21 CERAMIC 220PF 10% 50V
C204 1-126-967-11 ELECT 47uF 20% 50V
C205 1-126-967-11 ELECT 47uF 20% 50V
C206 1-128-560-11 ELECT 22uF 20% 100V
C208 1-126-965-11 ELECT 22uF 20% 50V
C210 1-130-493-00 MYLAR 0.068uF 5% 50V
C211 1-130-493-00 MYLAR 0.068uF 5% 50V
C225 1-162-284-31 CERAMIC 150PF 10% 50V
(EXCEPT XB80AV)
C225 1-162-294-31 CERAMIC 0.001uF 10% 50V
(XB80AV)
C226 1-162-284-31 CERAMIC 150PF 10% 50V
(EXCEPT XB80AV)
C226 1-162-294-31 CERAMIC 0.001uF 10% 50V
(XB80AV)
C228 1-164-159-21 CERAMIC 0.1uF 50V
C232 1-162-284-31 CERAMIC 150PF 10% 50V
C251 1-128-582-11 ELECT 10uF 20% 100V
C252 1-162-292-31 CERAMIC 680PF 10% 50V
C253 1-162-286-21 CERAMIC 220PF 10% 50V
C254 1-126-967-11 ELECT 47uF 20% 50V
C255 1-126-967-11 ELECT 47uF 20% 50V
C256 1-128-560-11 ELECT 22uF 20% 100V
C260 1-130-493-00 MYLAR 0.068uF 5% 50V
C261 1-130-493-00 MYLAR 0.068uF 5% 50V
C299 1-161-494-00 CERAMIC 0.022uF 25V
(XB80AV)
C301 1-126-959-11 ELECT 0.47uF 20% 50V
C302 1-126-923-11 ELECT 220uF 20% 10V
C303 1-126-933-11 ELECT 100uF 20% 10V
C304 1-126-961-11 ELECT 2.2uF 20% 50V
