– 122 –
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
C305 1-126-933-11 ELECT 100uF 20% 10V
C331 1-126-924-11 ELECT 330uF 20% 10V
C401 1-126-963-11 ELECT 4.7uF 20% 50V
C402 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C403 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C404 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C405 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C406 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C407 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C408 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C409 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C410 1-161-494-00 CERAMIC 0.022uF 25V
(EXCEPT XB80AV)
C410 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C411 1-161-494-00 CERAMIC 0.022uF 25V
(EXCEPT XB80AV)
C411 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C412 1-161-494-00 CERAMIC 0.022uF 25V
(EXCEPT XB80AV)
C412 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
C413 1-161-494-00 CERAMIC 0.022uF 25V
(EXCEPT XB80AV)
C413 1-164-159-21 CERAMIC 0.1uF 50V
(XB80AV)
< CONNECTOR >
* CN201 1-766-957-11 CONNECTOR, BOARD TO BOARD 20P
< DIODE >
D101 8-719-510-68 DIODE D5SBA20F01
D102 8-719-025-03 DIODE RBA-402-SL
D103 8-719-991-33 DIODE 1SS133T-77 (XB80AV)
D104 8-719-200-82 DIODE 11ES2
D105 8-719-200-82 DIODE 11ES2
D110 8-719-200-82 DIODE 11ES2
D111 8-719-200-82 DIODE 11ES2
D201 8-719-991-33 DIODE 1SS133T-77
D251 8-719-991-33 DIODE 1SS133T-77
D301 8-719-991-33 DIODE 1SS133T-77
D302 8-719-991-33 DIODE 1SS133T-77
D303 8-719-991-33 DIODE 1SS133T-77
D321 8-719-991-33 DIODE 1SS133T-77
D331 8-719-991-33 DIODE 1SS133T-77
D332 8-719-991-33 DIODE 1SS133T-77
D401 8-719-991-33 DIODE 1SS133T-77
D402 8-719-991-33 DIODE 1SS133T-77
D403 8-719-991-33 DIODE 1SS133T-77
D404 8-719-991-33 DIODE 1SS133T-77
D405 8-719-991-33 DIODE 1SS133T-77
D406 8-719-991-33 DIODE 1SS133T-77
< EARTH TERMINAL >
* EP101 1-537-738-21 TERMINAL, EARTH
* EP201 1-537-738-21 TERMINAL, EARTH
< FUSE >
! F101 1-533-311-11 FUSE, GLASS CYLINDRICAL (DIA. 5) (8A/125V)
(D890AV)
! F101 1-532-504-31 FUSE, TIME-LAG (4A/250V) (EXCEPT D890AV)
! F102 1-533-311-11 FUSE, GLASS CYLINDRICAL (DIA. 5) (8A/125V)
(D890AV)
! F102 1-532-504-31 FUSE, TIME-LAG (4A/250V) (EXCEPT D890AV)
! F103 1-532-506-31 FUSE, TIME-LAG (6.3A/250V) (EXCEPT D890AV)
! F103 1-533-312-11 FUSE, CLASS CYLINDRICAL (DIA. 5) (10A/125V)
(D890AV)
! F104 1-532-506-31 FUSE, TIME-LAG (6.3A/250V) (EXCEPT D890AV)
! F104 1-533-312-11 FUSE, CLASS CYLINDRICAL (DIA. 5) (10A/125V)
(D890AV)
< FUSE HOLDER >
FH101 1-533-233-21 HOLDER, FUSE
FH102 1-533-233-21 HOLDER, FUSE
FH103 1-533-233-21 HOLDER, FUSE
FH104 1-533-233-21 HOLDER, FUSE
FH105 1-533-233-21 HOLDER, FUSE
FH106 1-533-233-21 HOLDER, FUSE
FH107 1-533-233-21 HOLDER, FUSE
FH108 1-533-233-21 HOLDER, FUSE
< IC >
IC201 8-749-921-68 IC STK-4231MK2
IC301 8-759-111-68 IC uPC1237HA
< COIL >
L401 1-420-872-00 COIL, AIR-CORE (XB80AV)
L402 1-420-872-00 COIL, AIR-CORE (XB80AV)
L403 1-420-872-00 COIL, AIR-CORE (XB80AV)
L404 1-420-872-00 COIL, AIR-CORE (XB80AV)
< TRANSISTOR >
Q111 8-729-029-66 TRANSISTOR DTC114ESA-TP (XB80AV)
Q112 8-729-029-66 TRANSISTOR DTC114ESA-TP (XB80AV)
Q113 8-729-040-20 TRANSISTOR RT1P137L-TP (XB80AV)
Q201 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q251 8-729-140-84 TRANSISTOR 2SC1841-PAFAEA
Q301 8-729-030-02 TRANSISTOR DTC144ESA-TP
Q323 8-729-029-40 TRANSISTOR DTA124ESA-TP
Q331 8-729-030-02 TRANSISTOR DTC144ESA-TP
Q401 8-729-029-66 TRANSISTOR DTC114ESA-TP
Q402 8-729-029-68 TRANSISTOR DTC114TSA-TP
Q403 8-729-040-20 TRANSISTOR RT1P137L-TP
Q404 8-729-040-20 TRANSISTOR RT1P137L-TP
Q405 8-729-029-66 TRANSISTOR DTC114ESA-TP
POWER
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
