– 129 –
R54 1-216-073-00 METAL CHIP 10K 5% 1/10W
R55 1-216-061-00 METAL CHIP 3.3K 5% 1/10W
R57 1-216-162-00 METAL CHIP 33 5% 1/8W
R58 1-216-013-00 METAL CHIP 33 5% 1/10W
R91 1-216-295-91 METAL CHIP 0 5% 1/10W
R92 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1751 1-247-807-31 CARBON 100 5% 1/4W
R1752 1-216-073-00 METAL CHIP 10K 5% 1/10W
R1753 1-216-067-00 METAL CHIP 5.6K 5% 1/10W
R1754 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1755 1-216-097-91 METAL CHIP 100K 5% 1/10W
R1756 1-249-401-11 CARBON 47 5% 1/4W F
R1757 1-216-295-91 METAL CHIP 0 5% 1/10W
< VARIABLE RESISTOR >
RV41 1-238-600-11 RES, ADJ, CARBON 10K
RV42 1-238-600-11 RES, ADJ, CARBON 10K
< TERMINAL >
TM1 1-537-488-11 TERMINAL BOARD (ANT) (ANTENNA)
< VIBRATOR >
X21 1-760-549-11 VIBRATOR, CRYSTAL (4.5MHz)
X41 1-767-825-21 FILTER, CERAMIC (10.7MHz)
X42 1-527-981-00 FILTER, CERAMIC (450KHz)
X1751 1-579-900-21 VIBRATOR, CRYSTAL (4.332MHz)
**************************************************************
* 1-664-012-11 TC-A SW BOARD
*************
< CONNECTOR >
CN612 1-506-486-11 PIN, CONNECTOR 7P
< DIODE >
D631 8-719-057-29 DIODE SML78423C-TP15 (·)(DECK A)
D632 8-719-057-29 DIODE SML78423C-TP15 (ª)(DECK A)
< RESISTOR >
R705 1-249-401-11 CARBON 47 5% 1/4W F
R706 1-249-403-11 CARBON 68 5% 1/4W F
R707 1-247-807-31 CARBON 100 5% 1/4W
R708 1-249-407-11 CARBON 150 5% 1/4W F
R709 1-249-407-11 CARBON 150 5% 1/4W F
R710 1-247-815-91 CARBON 220 5% 1/4W
R711 1-247-807-31 CARBON 100 5% 1/4W
R712 1-247-807-31 CARBON 100 5% 1/4W
R713 1-247-807-31 CARBON 100 5% 1/4W
R714 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S641 1-554-303-21 SWITCH, TACTILE (·)(DECK A)
S642 1-554-303-21 SWITCH, TACTILE (ª)(DECK A)
S643 1-554-303-21 SWITCH, TACTILE (p)(DECK A)
S644 1-554-303-21 SWITCH, TACTILE (0)(DECK A)
S645 1-554-303-21 SWITCH, TACTILE ())(DECK A)
S646 1-554-303-21 SWITCH, TACTILE (DOLBY NR)
S647 1-554-303-21 SWITCH, TACTILE (DIRECTION)
**************************************************************
* 1-664-013-11 TC-B SW BOARD
*************
< DIODE >
D635 8-719-057-29 DIODE SML78423C-TP15 (ª)(DECK B)
D636 8-719-057-29 DIODE SML78423C-TP15 (·)(DECK B)
D637 8-719-058-17 DIODE LNJ401NPYJA (P)(DECK B)
D638 8-719-057-09 DIODE LNJ801LPDJA (r REC)(DECK B)
< RESISTOR >
R715 1-247-815-91 CARBON 220 5% 1/4W
R716 1-249-411-11 CARBON 330 5% 1/4W
R717 1-249-413-11 CARBON 470 5% 1/4W F
R718 1-249-415-11 CARBON 680 5% 1/4W F
R719 1-249-417-11 CARBON 1K 5% 1/4W F
R720 1-249-419-11 CARBON 1.5K 5% 1/4W F
R721 1-249-421-11 CARBON 2.2K 5% 1/4W F
R722 1-247-843-11 CARBON 3.3K 5% 1/4W
R723 1-247-807-31 CARBON 100 5% 1/4W
R724 1-247-807-31 CARBON 100 5% 1/4W
R725 1-247-807-31 CARBON 100 5% 1/4W
R726 1-247-807-31 CARBON 100 5% 1/4W
R727 1-247-807-31 CARBON 100 5% 1/4W
R728 1-247-807-31 CARBON 100 5% 1/4W
< SWITCH >
S651 1-554-303-21 SWITCH, TACTILE (·)(DECK B)
S652 1-554-303-21 SWITCH, TACTILE (ª)(DECK B)
S653 1-554-303-21 SWITCH, TACTILE ())(DECK B)
S654 1-554-303-21 SWITCH, TACTILE (0)(DECK B)
S655 1-554-303-21 SWITCH, TACTILE (p)(DECK B)
S656 1-554-303-21 SWITCH, TACTILE (P)(DECK B)
S657 1-554-303-21 SWITCH, TACTILE (r REC)(DECK B)
S658 1-554-303-21 SWITCH, TACTILE (H. SPEED DUBB)
S659 1-554-303-21 SWITCH, TACTILE (CD SYNC)
**************************************************************
* 1-663-994-11 TRANS BOARD (XB80AV)
************
< CONNECTOR >
* CN501 1-564-527-11 PLUG, CONNECTOR 12P
CN502 1-774-108-11 PIN, CONNECTOR (PC BOARD) 2P
< RESISTOR >
! R501 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
! R502 1-219-120-11 FUSIBLE 0.15 5% 1/4W F
< TRANSFORMER >
! T501 1-431-139-11 TRANSFORMER, POWER
************************************************************
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
TRANSTC-B SW
TC-A SW
The components identified by
mark ! or dotted line with mark
! are critical for safety.
Replace only with part number
specified.
Les composants identifiés par une
marque ! sont critiques pour la
sécurité.
Ne les remplacer que par une
piéce portant le numéro spécifié.
